Supermicro SuperWorkstation SYS-5039A-IL LGA1151 500W Mid-Tower Workstation Barebone System (Black)

Specifications

• Mfr Part Number: SYS-5039A-IL
• Motherboard: Super X11SAE
• Processor: LGA1151
  • Supports Intel Xeon E3-1200 v5 Series Processors
  • CPU TDP up to 80W
• Chipset: Intel C236
• Memory: 4x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, ECC, Unbuffered, Max Capacity of 64GB
• Slots: 2x PCI-Express 3.0 x16 Slots (x16/NA or x8/x8), 2x PCI-Express 3.0 x4 Slots (run at x1), 2x PCI Slots (32-bit)
• SATA: 8x SATA3 Ports, via Intel C236 Support RAID 0, 1, 5, 10
• Audio: Realtek ALC888S 7.1 Channel High Definition Audio CODEC
• Video: ASPEED AST2400 BMC Graphics
• LAN: Intel i210AT and Intel PHY i219LM Gigabit Ethernet Controllers
• Drive Bays: 4x 3.5" Internal Fixed Drive Bays, 2x 5.25" Peripheral Drive Bays
• Ports: 2x USB 3.1 Ports (rear), 6x USB 3.0 Ports (2 rear, 4 via headers), 8x USB 2.0 Ports (2 rear, 6 via headers), 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x DisplayPort, 2x RJ45 LAN Ports, Audio I/O Jacks
• Form Factor: Mid-Tower
• Power Supply: 500W 80 PLUS Bronze Certified AC Power Supply w/ PFC
• System Cooling: 1x 120mm Rear Exhaust Fan w/ Optimal Fan Speed Control
• Front Panel:
  • Buttons: Power On/Off
  • LEDs: Power, Hard Drive Activity, Network Activity, System Information
• Color: Black
• Dimension (WxDxH): 7.60 x 20.68 x 16.70 inch / 193.0 x 525.3 x 424.0 mm
• Gross Weight: 40.0 lbs / 18.1 kg
• RoHS Compliant
