Supermicro SuperWorkstation SYS-5038A-IL LGA1150 500W Mid-Tower Workstation Barebone System (Black)

Specifications

• Mfr Part Number: SYS-5038A-IL
• Motherboard: Super X10SAE
• Processor: LGA1150
  • Supports Intel Xeon E3-1200 v3 Series Processors
  • Supports 4th Generation Intel Core i7/ i5/ i3, Pentium & Celeron Processors
• Chipset: Intel C226 Express PCH
• Memory: 4x 240pin DDR3-1600 DIMM Slots, ECC/Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 2x PCI-Express 3.0 x16 Slots (run at x16 or x8/x8), 3x PCI-Express 2.0 x4 Slots (run at x1), 2x PCI Slots (32-bit)
• SATA: 8x SATA3 Ports, Six via PCH Support RAID 0, 1, 5, 10, Two via ASM1061
• Audio: Realtek ALC1150 7.1-Channel High Definition Audio CODEC
• LAN: Intel i217LM and Intel i210AT Gigabit Ethernet Controllers
• Drive Bays: 4x 3.5" SAS/SATA Internal HDD Bays, 1x 5.25" Standard Peripheral Drive Bay, 1x 3.5" Internal Fixed Peripheral Drive Bay
• Ports: 6x USB 3.0 Ports (2 rear, 4 via headers), 10x USB 2.0 Ports (4 rear, 6 via headers), 1x VGA Port, 1x DVI Port, 1x HDMI Port, 1x DisplayPort, 2x RJ45 LAN Ports, Audio I/O Jacks
• Form Factor: Mid-Tower
• Power Supply: 500W 80 PLUS Bronze Certified AC Power Supply w/ PFC
• System Cooling: 1x 120mm Rear Exhaust Fan w/ Optimal Fan Speed Control
• Front Panel:
  • Buttons: Power On/Off
  • LEDs: Power, Hard Drive Activity, Network Activity, System Overheat
• Color: Black
• Dimension (WxDxH): 7.60 x 20.68 x 16.70 inch / 193.0 x 525.3 x 424.0 mm
• Gross Weight: 40.0 lbs / 18.1 kg
• RoHS Compliant
