Seasonic M12II EVO Edition SS-620GM2 620W 80 PLUS Bronze ATX12V/EPS12V Power Supply

Specifications

• Mfr Part Number: M12II 620 BRONZE;SS-620GM2

• Features:
  • DC to DC Converter Design
  • Highly Reliable 105Ìâå¡C Aluminum Electrolytic Capacitors
  • Ample +12V Outputs
  • Active Power Factor Correction (up to 99%)
  • Smart & Silent Fan Control (S²FC)
  • Multi-GPU Technology Support
  • Fully Modular Cables
  • Universal AC Input (Full Range)
  • Ultra Ventilation (Honeycomb Structure)
  • Gold Plated High Current Terminals (MB, CPU, and PCIe)
• Type: ATX12V / EPS12V

• Total Power: 620 W

• Input:
  • Voltage: 100 - 240V
  • Current: 9 - 4.5A

  • Frequency: 50/60Hz

• Power Factor Correction: Active PFC
• Efficiency: 80 PLUS Bronze/ Energy Star/ ErP Lot 6 2013 Compliant

• Output: +3.3V @ 24A, +5V @ 24A, +12V @ 48A,  -12V @ 0.8A, +5VSB @ 2.5A

• Connector: 1x 20+4pin Main Power Connector, 1x 4/8pin 12V CPU Power Connector, 8x SATA Connectors, 4x 6+2pin PCI Express Connectors, 5x Peripheral Connectors, 1x Floppy Connector

• Cooling System: 120mm Ball Bearing Cooling Fan
• Dimension (WxLxH): 150.0 x 160.0 x 86.0 mm

• RoHS Compliant
