MSI Z270 GAMING M5 LGA1151/ Intel Z270/ DDR4/ 3-Way CrossFireX & 2-Way SLI/ SATA3&USB3.1/ M.2/ A&GbE/ ATX Motherboard

SpecificationsMfr Part Number: Z270 GAMING M5CPU: LGA1151Supports 7th/6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron ProcessorsChipset: Intel Z270Memory: 4x DDR4-3800(OC)/ 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400/ 2133 MHz Slots (7th Gen processors) or 4x DDR4-3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400(OC)/ 2133 MHz Slots (6th Gen processors), Dual Channel, Non-ECC, Unbuffered, Max Capacity of 64GBSlots: 3x PCI-Express 3.0 x16 Slots (support x16/x0/x4, x8/x8/x4 modes), 3x PCI-Express 3.0 x1 SlotsMulti-Graphics: Supports AMD 3-Way CrossFireX Technology and NVIDIA 2-Way SLI TechnologyStorage:SATA: 6x SATA3 PortsM.2: 2x M.2 Ports (Key M), Support SATA3 & PCI Express 3.0 x4, one supports type 2242/ 2260/ 2280/ 22110, one supports type 2242/ 2260/ 2280Audio: Realtek ALC1220 7.1-Channel High Definition Audio CODECLAN: Killer E2500 Gigabit Ethernet ControllerPorts: 2x USB 3.1 Gen2 Ports (1 Type-A rear, 1 Type-C rear), 6x USB 3.1 Gen1 Ports (2 Type-A rear, 4 via headers), 7x USB 2.0 Ports (3 Type-A rear, 4 via headers), 1x PS/2 Keyboard/Mouse Combo Port, 1x DisplayPort, 1x HDMI Port, 1x Optical S/PDIF Out, 1x RJ45 LAN Port, Audio I/O JacksPower Connector: 1x 24pin ATX Main Power Connector, 1x 8pin ATX 12V Power ConnectorForm Factor: ATX, 12.0 x 9.6 inch / 30.5 x 24.4 cm
