HPE ProLiant DL160 Gen9 Performance Servers - 769506-B21

Brand:
(No reviews yet) Write a Review
Part Number #
769506-B21
Availability:
In Stock
MSRP: £7,028.16
£5,856.79
Inc. VAT
MSRP: £5,856.80
£4,880.66
Ex. VAT
— You save £1,171.37
Get Bulk Pricing
Don't like the price? Make an offer!

Description

Main Specifications

Product Description HPE ProLiant DL160 Gen9 Performance - Xeon E5-2630V3 2.4 GHz - 32 GB - 0 GB
Type Server - rack-mountable
Height (Rack Units) 1U
Localization Worldwide
Server Scalability 2-way
Processor 2 x Intel Xeon E5-2630V3 / 2.4 GHz ( 3.2 GHz ) ( 8-core )
Cache Memory 40 MB L3 cache
Cache Per Processor 20 MB
RAM 32 GB (installed) / 256 GB (max) - DDR4 SDRAM - Advanced ECC - 1866 MHz - PC4-17000
Storage Controller RAID ( SATA 6Gb/s / SAS 12Gb/s ) - PCIe 3.0 x8 ( Smart Array P440 with 4GB FBWC )
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Graphics Controller Matrox G200eH2
Networking GigE
Power AC 120/230 V ( 50/60 Hz )
Power Redundancy Yes
Dimensions (WxDxH) 17.1 in x 23.9 in x 1.7 in
Weight 22.05 lbs
Manufacturer Warranty 3 years warranty - on-site ( 1st year only )



Extended Specifications

General
Type Server
Product Form Factor Rack-mountable - 1U
Embedded Security Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability 2-way
Front Accessible Bays Qty 1
Hot-Swap Bays Qty 8
Localization Worldwide
Processor / Chipset
CPU Intel Xeon E5-2630V3 / 2.4 GHz
Max Turbo Speed 3.2 GHz
Number of Cores 8-core
CPU Qty 2
Max CPU Qty 2
CPU Upgradability Upgradable
Cache Memory
Installed Size L3 cache - 40 MB
Cache Per Processor 20 MB
RAM
Installed Size 32 GB / 256 GB (max)
Technology DDR4 SDRAM - Advanced ECC
Memory Speed 1866 MHz
Memory Specification Compliance PC4-17000
Form Factor DIMM 288-pin
Features Registered, Online Spare Memory, quad channel memory architecture, HP SmartMemory
Configuration Features 2 x 16 GB
RAM Supported PC4-17000 - 256 GB - registered ¦ PC4-17000 - 512 GB - Load-Reduced
Hard Drive
Type No HDD
Storage Controller
Type 1 x RAID - plug-in card - PCIe 3.0 x8
Controller Interface Type SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name Smart Array P440 with 4GB FBWC
RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size 4 GB
Monitor
Monitor Type None.
Graphics Controller
Type Integrated
Graphics Processor Matrox G200eH2
Video Interfaces VGA
Networking
Type Integrated
Interface (Bus) Type PCI Express 2.0 x2
Ethernet Ports 2 x Gigabit Ethernet
Ethernet Controller HP NC361i
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL), PXE support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF ¦ 1 (total) / 1 (free) x external 5.25" Slim Line
Slots 2 (total) / 0 (free) x CPU ¦ 16 (total) / 14 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 1 (total) / 0 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HP iLO - RJ-45 ¦ 1 x VGA ¦ 1 x USB 2.0 ( 1 in front ) ¦ 3 x USB 3.0 ( 2 rear, 1 internal )
Miscellaneous
Included Accessories HP Easy Install Rails
Features Administrator password, power-on password, serial port I/O control, UEFI BIOS
Compliant Standards ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Power
Device Type Power supply
Power Redundancy Yes
Power Redundancy Scheme 1+1
Installed Qty 2
Max Supported Qty 2
Nominal Voltage AC 120/230 V ( 50/60 Hz )
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Gold
Efficiency 92%
Operating System / Software
OS Certified SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris
Manufacturer Warranty
Service & Support 3 years warranty
Service & Support Details Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labor - 1 year - on-site - response time: next business day
Dimensions & Weight
Width 17.1 in
Depth 23.9 in
Height 1.7 in
Weight 22.05 lbs
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% (non-condensing)
Sound Emission 34.9 dBA
