GIGABYTE GA-970A-DS3P Socket AM3+/ AMD 970/ DDR3/ SATA3&USB3.0/ A&GbE/ ATX Motherboard

Specifications

• Mfr Part Number: GA-970A-DS3P
• CPU: Socket AM3+
  • Supports AMD AM3+ FX Processors
  • Supports AMD AM3 Phenom II / AMD Athlon II Processors
  • Hyper Transport Bus up to 4800 MT/s
• Chipset: North Bridge AMD 970 & South Bridge AMD SB950
• Memory: 4x DDR3-2000(OC)/1866/1600/1333/1066 DIMM Slots, Dual Channel, Max Capacity of 32GB
• Slots: 2x PCI-Express 2.0 x16 Slots (one runs at x4), 3x PCI-Express 2.0 x1 Slots, 2x PCI Slots
• SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10, JBOD
• Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC
• LAN: Realtek Gigabit Ethernet Controller
• Ports: 4x USB 3.0/2.0 Ports (2 rear, 2 via hearder), 12x USB 2.0/1.1 Ports (6 rear, 6 via headers), 1x PS/2 Keyboard Port, 1x PS/2 Mouse Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Main Power Connector, 1x 4pin ATX 12V Power Connector
• Form Factor: ATX, 30.5 x 21.5 cm
