D-Link DES-1210-28P Web Smart-III 24-Port 10/100 POE Switch w/ 2x Gigabit Ports & 2 Combo SFP Slots

SpecificationsMfr Part Number: DES-1210-28PFeatures: Green TechnologyAdvanced Security FeaturesQoS & Bandwidth ControlAdvanced Features like LBD and Cable DiagnosticsVoIP DeploymentTime basd PoE functionAutomatic detection of 802.3af or pre-standard 802.3at power device to feed power according to defined classificationInterface: 24x 10/100Mbps BASE-Tx PoE2x 10/100/1000BASE-T2x combo 10/100/1000BASE-T/SFPPort Standards & Functions: IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)IEEE 802.3z Gigabit Ethernet (fiber) ANSI/IEEE 802.3Auto-negotiationIEEE 802.3x Flow ControlPower over Ethernet(PoE)PoE Standard: 802.3 af & 802.3 atPoE capable ports: Port 1-4 upto 15.4 or 30W per port; Port 5-24 upto 15.4W per portPoE Power Budget: 193 WMedia Interface Exchange: Auto MDI/MDIX adjustment for all twisted-pair portsPerformanceSwitching Capacity: 12.8 GbpsTransmission Method: Store-and-forwardMAC Address Table: 8K entries per deviceMaximum 64 bytes packet forwarding rate: 9.5 MppsFlash Memory: 16 MBL2 Features: MAC Address Table: 8K entriesFlow Control: 802.3x Flow Control; HOL Blocking PreventionIGMP Snooping: IGMP v1/v2 Snooping; Supports 64 static multicast addresses; Supports 256 IGMP Snooping groups; per VLAN IGMP Snooping; Supports IGMP QuerierL2 Multicast Filtering: Forwards all unregistered groups, Filters all unregistered groupsSpanning Tree Protocol: 802.1D STP; 802.1w RSTPLoopback Detection: Yes802.3ad Link Aggregetion: Max 8 groups per device, max 8 ports per groupPort Mirroring: One-to-One, Many-to-One, Supports Mirroring for Tx/Rx/BothCable Diagnostics: YesConfigurable Auto MDI/MDI-X: YesQoS: 802.1pMax 8 queues per port, max 8 ports per queueQueue Handling: Strict, Weighted Round Robin (WRR)CoS based on: 802.1p Priority Queues, DSCPBandwidth Control: Port-based (Ingress/Egress, min. granularity 64 Kb/s for 10/100 Mbps and 1850 Kb/s for 1000 Mbps)Security: 802.1X: Port-based access controlPort Security: Supports up to 64 MAC addresses per portTraffic Control: Broadcast/Multicast/Unicast Storm ControlStatic MAC: YesD-Link Safeguard Engine: YesDHCP Server Screening: YesARP Spoofing Prevention: Max 64 entriesSSL: Supports v1/v2/v3Management: Web-based GUI: YesCompact CLI through Telnet: YesTelnet Server: YesSmartConsole Utility: YesTFTP Client: YesSNMP: Supports v1/v2/v3SNMP Trap: YesTrap for SmartConsole Utility: YesSystem Log: Max. 500 log entries, supports IPv4 log serverBootP/DHCP Client: YesTime Setting: SNTPLLDP-MED???«LLDPTime-based PoEMTBF: 197,343 hoursAcoustics: 59.3 dBAC Input: 100 ~ 240V AC, 50 ~ 60 Hz internal universal power supplyMax Power Consumption: PoE ON - 256 W; PoE OFF - 26.4 WCooling system: 3 Smart FansDimensions(WxDxH): 440.0 x 250.0 x 44.0 mm
