ASROCK Z390M-ITX/AC LGA1151/ Intel Z390/ DDR4/ SATA3&USB3.1/ M.2/ WiFi/ A&2GbE/ Mini-ITX Motherboard

Specifications

• Mfr Part Number: Z390M-ITX/AC
• CPU: LGA1151
  • Supports 9th and 8th Generation Intel Core processors

  • Digi Power design

  • 6 Power Phase design

  • Supports Intel Turbo Boost 2.0 Technology

  • Supports Intel K-Series unlocked CPUs

  • Supports ASRock BCLK Full-range Overclocking

• Chipset: Intel Z390
• Memory: 2x DDR4-4000+(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3200(OC)/ 2933(OC)/ 2800(OC)/ 2666/ 2400/ 2133 MHz DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot

• Storage:
  • SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10
  • M.2: 1x Ultra M.2 Port (w/ M key), supports type 2230/ 2242/ 2260/ 2280 M.2 SATA3 and M.2 PCI-Express 3.0 x4 (32 Gb/s)

• Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC

• LAN: Giga PHY Intel I219V and Intel I211AT Gigabit Ethernet Controllers; Dual-Band IEEE 802.11a/b/g/n/ac Wireless LAN (2.4/5GHz); Bluetooth 4.2 / 3.0 + High speed class II

• Ports: 6x USB 3.1 Gen 2 Ports (5 Type-A rear, 1 Type-C rear), 2x USB 3.1 Gen 1 Ports (front), 4x USB 2.0 Ports (2 rear, 2 front), 1x PS/2 mouse/keyboard Port, 2x HDMI Ports, 1x DisplayPort, 2x Antenna Ports, 2x RJ45 LAN Ports with LED, Audio I/O Jacks

• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin 12V Power connector

• Form Factor: Mini-ITX, 6.7 x 6.7  inch / 17.0 x 17.0 cm
