ASRock H270M-ITX/AC LGA1151/ Intel H270/ DDR4/ SATA3&USB3.0/ M.2/ WiFi/ A&2GbE/ Mini-ITX Motherboard

Specifications

• Mfr Part Number: H270M-ITX/AC
• CPU: LGA1151
  • Supports 6th/ 7th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • Digi Power design
  • 6 Power Phase design
  • Supports Intel Turbo Boost 2.0 Technology
• Chipset: Intel H270
• Memory: 2x DDR4-2400/ 2133 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot
• Storage:
  • SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10, NCQ, AHCI and Hot Plug
  • M.2: 1x Ultra M.2 Port, Support Type 2230/ 2242/ 2260/ 2280 M.2 SATA3 & M.2 PCI-Express 3.0 x4 (32 Gb/s)
• Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC
• LAN: Intel I211V and Giga PHY Intel I219V Gigabit Ethernet Controller; IEEE 802.11a/b/g/n/ac Wireless LAN (2.4/5GHz); Bluetooth 4.0 / 3.0 + High speed class II
• Ports: 8x USB 3.0 Ports (6 rear, 2 via header), 4x USB 2.0 Ports (2 rear, 2 via header), 1x PS/2 Mouse/Keyboard Port, 1x DVI-D Port, 2x HDMI Ports, 2x RJ45 LAN Ports, 2x Antenna Ports, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin 12V Power Connector
• Form Factor: Mini-ITX, 6.7 x 6.7 inch / 17.0 x 17.0 cm
