ASRock A88M-G/3.1 Socket FM2+/ AMD A88X/ DDR3/ Quad CrossFireX/ SATA3&USB3.1/ M.2/ A&GbE/ MicroATX Motherboard

Specifications

• Mfr Part Number: A88M-G/3.1
• CPU: Socket FM2+
  • Supports Socket FM2+ 95W/ FM2 100W Processors
  • 4 + 2 Power Phase design
• Chipset: AMD A88X (Bolton-D4)
• Memory: 4x DDR3-2400+(OC)/ 2133/ 1866/ 1600/ 1333/ 1066 DIMM Slots, Dual Channel, Non-ECC, Un-buffered, Max Capacity of 64GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x PCI-Express 2.0 x16 Slot (runs at x4), 1x PCI-Express 2.0 x1 Slot, 1x PCI Slot
• Multi-Graphics: Supports AMD Quad CrossFireX, CrossFireX Technology
• Storage:
  • SATA: 8x SATA3 Ports, Support RAID 0, 1, 5, 10
  • M.2: 1x M.2 Port, Supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen2 x4 (20 Gb/s)
• Audio: Realtek ALC1150 7.1-Channel High Definition Audio CODEC; Supports Premium Blu-ray Audio
• Video: Integrated AMD Radeon R7/R5 Series Graphics in A-series APU w/ 2GB Max Shared Memory
• LAN: Realtek RTL8111GR PCI-Express x1 Gigabit Ethernet Controller
• Ports: 2x USB 3.1 Ports (1 Type A, 1 Type C), 4x USB 3.0 Ports (2 rear, 2 via header), 6x USB 2.0 Ports (2 rear, 4 via headers), 1x PS/2 Keyboard/Mouse Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin 12V Power Connector
• Form Factor: MicroATX

• Product images are for illustrative purposes only therefore the delivered product may vary from the one shown above.
• In some cases, packaging may differ from OEM/original retail box. For bulk orders that are packaged together, product manuals or CDs may not always be available for each item.
• The shipping cost added at the checkout is a general estimate which is subject to change depending on size/weight/quantity of ordered goods.
• Orders that contain end of life (EOL) products that are no longer in production may be replaced by a compatible product with the same FRU number offering same functionality.
• Refurbished printers may not have full ink cartridges or laser toners.
• Once an order is processed at our warehouse, it cannot be cancelled. A returned order will likely incur a restocking fee. See RMA page for details about restocking fees.
• Please note if you are concerned about any of the above conditions or have any questions, we highly recommend that you contact us on sales@ithardwaregroup.co.uk or call 020 37908599 before placing an order
