| Print quality |
|---|
| Maximum resolution | 300 |
| Printing |
|---|
| Print speed | 102 mm/sec |
| Maximum resolution | 300 |
| Print technology | Thermal transfer |
| Networking |
|---|
| Network ready | Yes |
| Ports & interfaces |
|---|
| Standard interfaces | Serial, Ethernet |
| RS-232 ports | 1 |
| RS-232 interface | Yes |
| Optional connectivity | Bluetooth, Parallel, Wireless LAN |
| Connectivity technology | Wired |
| Memory |
|---|
| Internal memory | 8 MB |
| Flash memory | 4 MB |
| Paper handling |
|---|
| Media thickness | 0.08 - 0.2 |
| Maximum roll diameter | 127 |
| Maximum label width | 4.25" (10.8 cm) |
| Maximum label length | 39" (0.991 m) |
| Autocutter | Yes |
| Performance |
|---|
| Built-in barcodes | CODABAR (NW-7),EAN128,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,PDF417,POSTNET,UPC-A,UPC-E |
| Ribbon width | 4.33" (11 cm) |
| Ribbon length | 2913.4" (74 m) |
| Design |
|---|
| Certification | FCC 15, VCCI, C, EN55022 B, EN6100-3-2, EN6100-3-3, EN55024, CCC, CB IEC 60950: 1991 +A1 +A2 + A3 +A4, TUV NRTL, IRAM, NOM, AAMI |
| Power |
|---|
| Power requirements | 100 - 240V, 50/60Hz |
| Technical details |
|---|
| Built-in barcodes | CODABAR (NW-7),EAN128,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,PDF417,POSTNET,UPC-A,UPC-E |
| Ribbon width | 4.33" (11 cm) |
| Ribbon length | 2913.4" (74 m) |
| Maximum label width | 4.25" (10.8 cm) |
| Maximum label length | 39" (0.991 m) |
| Emulations | EPL, ZPL |
| Certificates |
|---|
| Certification | FCC 15, VCCI, C, EN55022 B, EN6100-3-2, EN6100-3-3, EN55024, CCC, CB IEC 60950: 1991 +A1 +A2 + A3 +A4, TUV NRTL, IRAM, NOM, AAMI |
| Software |
|---|
| Drivers included | Yes |
| Weight & dimensions |
|---|
| Width | 7.64" (194 mm) |
| Depth | 10" (254 mm) |
| Height | 7.52" (191 mm) |
| Weight | 4.63 lbs (2.1 kg) |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 5 - 41 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging data |
|---|
| Package weight | 9.04 lbs (4.1 kg) |
| Packaging content |
|---|
| Drivers included | Yes |
| Other features |
|---|
| Network ready | Yes |
| Emulations | EPL, ZPL |
