| Print quality |
|---|
| Maximum resolution | 203 x 203 DPI |
| Printing |
|---|
| Colour | No |
| Standard printer languages | EPL,EPL2,XML,ZPL,ZPL II |
| Print speed | 127 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Maximum print size | 104 x 991 mm |
| Print technology | Direct thermal |
| Networking |
|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ports & interfaces |
|---|
| Standard interfaces | Ethernet |
| USB 1.1 ports quantity | 1 |
| RS-232 ports | 1 |
| RS-232 interface | Yes |
| Optional connectivity | Parallel |
| Connectivity technology | Wired |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Memory |
|---|
| Internal memory | 8 MB |
| Flash memory | 4 MB |
| Paper handling |
|---|
| Media thickness (imperial) | 0.003 - 0.0075 |
| Media thickness | 0.08 - 0.2 |
| Maximum roll diameter | 127 |
| Maximum label width | 4.25" (10.8 cm) |
| Maximum label length | 39" (0.991 m) |
| Performance |
|---|
| Built-in barcodes | 1D,2D,Code 128 (A/B/C),Code 39,Code 49,Code 93,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,Matrix 2/5,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E |
| Built-in processor | 32-bit RISC |
| Design |
|---|
| Colour of product | Grey |
| Certification | FCC 15, VCCI, C-Tick, EN55022 B, EN6100-3-2, EN6100-3-3, EN55024, CCC CB IEC 60950: 1991 +A1 +A2 + A3 +A4, TUV NRTL, IRAM, NOM, AAMI |
| Power |
|---|
| Power requirements | 100 - 240 VAC, 50 - 60 Hz |
| Energy Star certified | No |
| Technical details |
|---|
| Colour of product | Grey |
| Built-in barcodes | 1D,2D,Code 128 (A/B/C),Code 39,Code 49,Code 93,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,Matrix 2/5,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E |
| Maximum label width | 4.25" (10.8 cm) |
| Maximum label length | 39" (0.991 m) |
| Processor |
|---|
| Built-in processor | 32-bit RISC |
| Certificates |
|---|
| Energy Star certified | No |
| Certification | FCC 15, VCCI, C-Tick, EN55022 B, EN6100-3-2, EN6100-3-3, EN55024, CCC CB IEC 60950: 1991 +A1 +A2 + A3 +A4, TUV NRTL, IRAM, NOM, AAMI |
| Weight & dimensions |
|---|
| Width | 6.73" (171 mm) |
| Depth | 8.23" (209 mm) |
| Height | 5.98" (152 mm) |
| Weight | 3.09 lbs (1.4 kg) |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 140 °F |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 5 - 41 °C |
| Operating temperature (T-T) | 40 - 105 °F |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging data |
|---|
| Package type | Box |
| Package weight | 7.05 lbs (3.2 kg) |
| Packaging content |
|---|
| Cables included | AC |
