XFX ProSeries P1-750B-BEFX 750W 80 PLUS Gold ATX12V v2.2 & ESP12V v2.91 Power Supply w/ Active PFC

Specifications

• Mfr Part Number: P1750BBEFX;P1-750B-BEFX
• Features:
  • Compatible with Intel Core i3, i5, i7 and AMD Phenom, FX
  • DC to DC Converter Design
  • Conductive Polymer Aluminum Solid Electrolytic Capacitors
  • Active Power Factor Correction (99% PF Typical)
  • High +12V Output
  • Ultra Ventilation (Grid Structure)
  • Multi-GPU Technologies Supported
  • All-in-One DC Cabling Design
  • Universal AC Input (Full Range)
• Type: ATX12V v2.2 & ESP12V v2.91
• Maximum Power: 750W
• Input:
  • Voltage: 100 - 240 V AC
  • Current: 9.5 - 4.5 A
  • Frequency Range: 50 - 60 Hz
• Output: +12V @ 62A, +3.3V @ 25A, +5V @ 25A, +5VSB @ 3A, -12V @ 0.5A
• Connectors: 1x 20+4pin Main Connector, 1x 4+4pin ATX12V / EPS12V Connector, 1x 8pin EPS 12V ATX12V / EPS12V Connector, 4x 6+2pin PCI-Express Connectors, 10x SATA Connectors, 5x Peripheral Connectors, 1x FDD Connector
• Cooling: 1x 120mm Fan
• Active PFC: >0.95 at full load
• Efficiency: Up to 90%
• Energy-Efficiency: 80 PLUS Gold Certified
• Protection: Over Voltage, Over Current, Over Power, Over Temperature, Under Voltage, Short Circuit
• Approvals: CB, C-tick, TUV
• Dimensions: 3.4 x 5.5 x 6.3 inch / 8.6 x 14.0 x 16.0 cm
