| Projector |
|---|
| Number of colours | 1.073 billion colors |
| Projector native resolution | 1080p (1920x1080) |
| Screen size compatibility | 95 - 120" |
| Projection distance | 4.72 - 9.84" (0.12 - 0.25 m) |
| Contrast ratio (typical) | 10000:1 |
| Matrix type | DMD |
| Matrix size | 0.65" |
| Projection technology | DLP |
| Projector brightness | 3300 ANSI lumens |
| Lamps |
|---|
| Service life of lamp | 3000 h |
| Bulb power | 240 W |
| Service life of lamp (economic mode) | 7500 h |
| Lamps quantity | 1 lamp(s) |
| Lens system |
|---|
| Fixed focal length | 0.132" (3.35 mm) |
| Aperture range (F-F) | 2.4 - 2.4 |
| Offset | 138% |
| Scanning frequency |
|---|
| Vertical scan range | 23 - 120 Hz |
| Horizontal scan range | 15 - 102 kHz |
| Video |
|---|
| Analog signal format system | NTSC,PAL,SECAM |
| Full HD | Yes |
| 3D | No |
| Supported video modes | 480i,480p,576i,576p,720p,1080i,1080p |
| Supported graphics resolutions | 640 x 480 (VGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA) |
| Ports & interfaces |
|---|
| Mobile High-Definition Link (MHL) | Yes |
| HDMI connector type | Full-size |
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| Composite video in | 1 |
| Audio (L,R) in | 1 |
| S-Video inputs quantity | 1 |
| RS-232 ports | 1 |
| PC Audio out | Yes |
| PC Audio in | Yes |
| DVI port | No |
| AC (power) in | Yes |
| Networking |
|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage |
|---|
| Card reader integrated | No |
| Sound emission |
|---|
| Noise level (economic mode) | 29 dB |
| Technical details |
|---|
| Colour of product | White |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Ceiling mounting supported | Yes |
| Performance |
|---|
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Vertical scan range | 23 - 120 Hz |
| Horizontal scan range | 15 - 102 kHz |
| Noise level (economic mode) | 29 dB |
| Design |
|---|
| Product type | Wall-mounted projector |
| Cable lock slot type | Kensington |
| Colour of product | White |
| Ceiling mounting supported | Yes |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Display |
|---|
| Built-in display | No |
| Power |
|---|
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power source | AC |
| Power consumption (typical) | 410 W |
| Power consumption (standby) | 0.5 W |
| Security |
|---|
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Indication |
|---|
| LED indicators | Yes |
| Software |
|---|
| Bundled software | vBoard |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating altitude | 0 - 59015.7" (0 - 1499 m) |
| Weight & dimensions |
|---|
| Weight | 13.9 lbs (6.3 kg) |
| Width | 17.1" (434 mm) |
| Depth | 15.3" (388 mm) |
| Height | 6.02" (153 mm) |
| Packaging content |
|---|
| Handheld remote control | Yes |
| Quick start guide | Yes |
| Cables included | AC, VGA |
| Bundled software | vBoard |
