TP-Link TL-WR702N 150Mbps Wireless N Nano Router

Specifications

• Mfr Part Number: TL-WR702N
• Hardware Features:
  • Interface: 1x 10/100Mbps WAN/LAN Port; 1x Micro USB Port; 1x Reset Button
  • Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Dimensions (WxDxH): 2.2 x 2.2 x 0.7 inch / 57.0 x 57.0 x 18.0 mm
  • Antenna Type: On-Board
• Wireless Features:
  • Frequency: 2.4-2.4835GHz
  • Signal Rate:
    • 11n: Up to 150Mbps (dynamic)
    • 11g: Up to 54Mbps (dynamic)
    • 11b: Up to 11Mbps (dynamic)
  • EIRP: <20dBm (EIRP)
  • Reception Sensitivity:
    • 135M: -70dBm@10%PER
    • 65M: -73dBm@10%PER
    • 54M: -76dBm@10%PER
  • Wireless Modes: AP Mode, Router Mode, Client Mode, Repeater Mode, Bridge Mode
  • Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
  • Wireless Security: 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
• Software Features:
  • WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP
  • DHCP: Server, Client, DHCP Client List, Address Reservation
  • Quality of Service: WMM, Bandwidth Control
  • Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
  • Dynamic DNS: DynDns, Comexe, NO-IP
  • VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head)
  • Access Control: Local Management Control, Host List, Access Schedule, Rule Management
  • Firewall Security:
    • DoS, SPI Firewall
    • IP Address Filter/MAC Address Filter/Domain Filter
    • IP and MAC Address Binding
  • Management:
    • Access Control
    • Local Management
    • Remote Management
• Others:
  • Certification: CE, FCC, RoHS
  • Package Contents: TL-WR702N, Power Adapter, USB Cable, Ethernet cable, Quick Installation Guide, Resource CD
  • System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
  • Environment:
    • Operating Temperature: 0^oC~40^oC (32^oF~104^oF)
    • Storage Temperature: -40^oC~70^oC (-40^oF~158^oF)
    • Operating Humidity: 10%~90% non-condensing
    • Storage Humidity: 5%~90% non-condensing
