Thermaltake Toughpower PS-TPD-1000MPCGUS-1 1000W 80 PLUS Gold ATX12V 2.3 & EPS12V Power Supply (Black)

Specifications

• Mfr Part Number: PS-TPD-1000MPCGUS-1
• Features:
  • Toughpower 1000W Gold
  • Ultra Quiet Fan
  • 80 PLUS Gold Certified and Haswell Ready
  • Flat Modular Cables
  • High Quality Japanese Capacitor
  • Massive and Dedicated + 12V Output
• Maximum Power: 1000 Watts
• Input:
  • Voltage: 100 VAC ~ 240 VAC
  • Current: 12 ~ 6A
  • Frequency Range: 50 ~ 60 Hz
• Form Factor: Intel ATX 12V V2.3 & EPS 12V
• Efficiency: 87~92% efficiency @ 20~100% load
• Hold-up Time: 16ms (minimum) @ 75% of full load at 115V / 230V input
• Power Good Signal: 100 ~ 500 msec
• Power Factor Correction: Active PFC
• Fan: 135mm double ball-bearing fan (1500RPM ±10%)
• MTBF: 120,000 hours
• Output: +3.3V @ 25A; +5V @ 25A; +12V @ 83A; -12V @ 0.3A; +5VSB @ 3.5A
• Connectors: 1x 24pin Main Connector, 1x 8pin EPS 12V Connector, 1x 4+4pin ATX 12V Connector, 6x 6+2pin PCI-Express Connectors, 12x 5pin SATA Connectors, 8x 4pin Peripheral Connectors, 1x Floppy Connector
• Safety/EMI: UL/ CB+Baurt mark/ CE/ FCC/ CCC/ GOST certification
• Color: Black
• Dimensions (WxDxH): 150.0 x 180.0 x 86.0 mm
