Supermicro SuperServer SYS-5017C-LF LGA1155 200W 1U Rackmount Server Barebone System (Black)

Specifications

• Mfr Part Number: SYS-5017C-LF
• Motherboard: Super X9SCL-F
• Processor: LGA1155
  • Supports Intel Xeon E3-1200 &v2 Series Processors
  • Supports 3rd and 2nd Generation Intel Core i3/ Pentium/ Celeron Processors
  • Supports up to 45W TDP
• Chipset: Intel C202 PCH
• Memory: 4x 240pin DDR3-1333/1066/800 DIMM Slots, Supports up to 32GB ECC/Unbuffered Memory
• Slots: 1x PCI-Express 2.0 x8 Slot (Low-profile)
• SATA: 6x SATA2 Ports, Support RAID 0, 1, 5, 10
• Video: Nuvoton WPCM450RA0BX Graphics
• LAN: Intel 82574L and 82579LM Gigabit Ethernet Controllers; 1x Realtek RTL8201N PHY (dedicated IPMI)
• Drive Bays: 1x 3.5" Hard Drive Bays
• Backplane: SAS/SATA HDD Backplane (SAS support requires optional SAS controller)
• Ports: 9x USB 2.0 Ports(2 rear, 6 via headers, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 1U Rackmount
• Power Supply: 200W Low Noise AC-DC Power Supply w/ PFC
• System Cooling: 2x 40x28mm 8500 RPM PWM Cooling Fans
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power, HDD Activity, 2x Network Activity, System Overheat
• Color: Black
• Dimensions (WxDxH): 17.2 x 11.3 x 1.7 inch / 437.0 x 287.0 x 43.0 mm
• Gross Weight: 11.0 lbs / 4.99 kg
• RoHS Compliant
