Supermicro SuperServer SYS-1028GR-TR Dual LGA2011 1000W/1600W 1U Rackmount Server Barebone System (Black)

Specifications

• Mfr Part Number: SYS-1028GR-TR BLACK
• Motherboard: Super X10DRG-H
• Processor: Dual LGA2011
  • Support Intel Xeon E5-2600 v3 Family Processors
  • Support up to 18 Cores
  • Cache up to 45MB
  • QPI up to 9.6 GT/s
  • Support up to 145W TDP
• Chipset: Intel C612 Express
• Memory: 16x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, Supports up to 1TB ECC/Load Reduced Memory or up to 512GB ECC/REG Memory
• Slots: 4x PCI-Express 3.0 x16 Slots (3x GPU/Xeon Phi cards optional), 1x PCI-Express 3.0 x16 Slot (Low-profile, runs at x8)
• SATA: 10x SATA3 Ports, Support RAID 0, 1, 5, 10
• Video: Aspeed AST2400 BMC Graphic
• LAN: Intel i350-AM2 Dual Port Gigabit Ethernet Controller
• Drive Bays: 4x 2.5" Hot-swap Drive Bays
• Ports: 4x USB 3.0 Ports (2 rear, 2 via header), 2x USB 2.0 Ports (2 via headers), 1x Serial Port (via header), 1x VGA Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Form Factor: 1U Rackmount
• Power Supply: 1000W/1600W 80 PLUS Platinum Level 1U Redundant Power Supply
• System Cooling: 10x Counter-rotating Fans w/ Optimal Fan Speed Control
• Front Panel:
  • Buttons: Power On/Off, System Reset
  • LEDs: Power, HDD Activity, 2x Network Activity, System Overheat/ Fan fail/ UID
• Color: Black
• Dimensions (WxDxH): 17.2 x 30.6 x 1.7 inch / 437.0 x 777.0 x 43.0 mm
• Gross Weight: 48.0 lbs / 21.8 kg
• RoHS Compliant
