Supermicro X7DBR-E Server Motherboard - Intel Chipset - Socket J LGA-771 - MBD-X7DBR-E-B

SpecificationsManufacturer: Supermicro Computer, IncManufacturer Part Number: MBD-X7DBR-E-BManufacturer Website Address: http://www.supermicro.comBrand Name: SupermicroProduct Model: X7DBR-EProduct Name: X7DBR-E Server MotherboardMarketing Information: Built upon the functionality and the capability of the 5000P chipset, the X7DBR-E Server Board provides the performance and feature set required for dual processor-based servers with configuration options optimized for communications, presentation, storage, computation or database applications.Product Type: Server MotherboardProcessor & ChipsetChipset Manufacturer: IntelTotal Processor Supported: 2Processor Socket: Socket J LGA-771Processor Supported: Xeon Quad-coreXeon Dual-CoreMemoryNumber of Memory Slots: 8Maximum Memory: 32 GBMemory Speed Supported: 667 MHz533 MHzMemory Standard: DDR2-667/PC2-5300DDR2-533/PC2-4200Memory Technology: DDR2 SDRAMI/O ControllerController Type: Floppy ControllerSerial ATA/300Ultra ATA/100 (ATA-6)RAID Supported: YesRAID Levels: 0151+0VideoOnboard Video: On-board Video ChipsetGraphics Controller Manufacturer: ATIGraphics Controller Model: ES1000Network & CommunicationGigabit Ethernet: YesInterfaces/PortsTotal Number of USB Ports: 2Number of USB 2.0 Ports: 2VGA: YesOnboard InterfacesNumber of SATA Interfaces: 6Total Number of Onboard USB Ports: 2Physical CharacteristicsForm Factor: Extended ATXWidth: 12"Depth: 13.1"MiscellaneousEnvironmentally Friendly: YesEnvironmental Certification: RoHS
