Supermicro AOC-TBT-DSL5320 Thunderbolt 2 Add-on Card

Specifications

• Mfr Part Number: AOC-TBT-DSL5320

• Form Factor: Single slot (3.71" length x 2.99" height) with full height bracket
• Chipset: DSL5320 Thunderbolt 2 controller (Falcon Ridge)

• Thunderbolt Connector: 1

• DisplayPort Connector: 1
• DisplayPort Revision: 1.2

• PCIe Connection: PCIe 2.0 x4 from PCH PCIe slot

• GPIO Connector: Needs GPIO cable to TBT GPIO header on MB (Supported on X10DAi/C/X, X10DAL and X10DRG-Q)

• Thunderbolt Bandwidth: 20 Gbps
• TBT AIC Power Consumption: 4.1W max
