Seasonic SSR-650SGX FOCUS 650W 80 PLUS Gold SFX12V/ATX12V Power Supply w/ Fully Modular

Specifications

• Mfr Part Number: SSR-650SGX
• Features:
  • 80 PLUS Gold certified

  • Compact SFX-L Size
  • Tight Voltage Regulation

  • Cable-free Connection Design
  • S3FC - Fanless until 30 % load

  • SFX to ATX Expandability

  • Gold plated connectors
  • 10 Years Warranty

• Type: Intel SFX 12V / ATX 12V

• Total Power: 650W

• Input:
  • Voltage: 100 - 240V

  • Current: 9 - 4.5 A

  • Frequency: 50 - 60Hz
• MTBF: 100,000 hours (@ 25 °C, excl. fan)

• Output: +3.3V @ 20A, +5V @ 20A, +12V @ 54A, -12V @ 0.3A, +5Vsb @ 3A

• Connectors: 1x 20/24-pin Main Power Connector; 1x 4/8-pin CPU Connector, 4x 6/8-pin PCI-Express Connectors, 6x SATA Connectors, 3x Molex Connectors, 1x Molex to FDD Adapter Connector

• Cooling System: 120mm Fluid Dynamic Bearing Fan w/ Premium Hybrid Fan Control

• Protection: OPP, OVP, UVP, OCP, OTP, SCP

• Safety and EMC: cTUVus, TUV, CB, CCC, BSMI, EAC, CE

• Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH

• Dimensions (WxLxH): 125.0 x 125.0 x 63.5 mm
