Plextor M8PeGN 256GB M.2 2280 PCI-Express 3.0 x4 Solid State Drive (MLC)

Specifications

• Mfr Part Number: PX-256M8PEGN(CX2-8B256-Q06)
• Capacity: 256 GB
• Form Factor: M.2 2280
• Interface: M.2 PCI-Express 3.0 x4 with NVM Express
• NAND Flash: TOSHIBA 15nm Toggle MLC
• Controller: Marvell 88SS1093
• DRAM Cache: 512MB LPDDR3
• Performance:
  • Sequential Read Rate: Up to 2,000 MB/s
  • Sequential Write Rate: Up to 900 MB/s
  • Random Read Rate: Up to 210,000 IOPS
  • Random Write Rate: Up to 230,000 IOPS
• Shock: 1500G (Max.), at 1 msec hal f-sine
• Vibration: 7 ~ 800Hz, 1.63Grms (Operating)
• MTBF: > 2,400,000 Hours
• Power Requirement: DC 3.3V 2.0A (Max.)
• Connectors:
  • Power: M.2 connector for DC 3.3V input
  • Data: M.2 Connector
• Operating System Supported: Microsoft Windows 8.1, 10/ Linux OS
• Certifications: UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
• Dimensions (WxLxH): 0.90 x 3.15 x 0.19 inch / 22.85 x 80.00 x 4.79 mm (w/ heat sink); 0.87 x 3.15 x 0.09 inch / 22.0 x 80.0 x 2.3 mm (w/o heat sink)
• Weight: 0.46 oz / 13.0 g (w/ heat sink); 0.35 oz / 10.0 g (w/o heat sink)
