MSI CSM-H170M-A PRO LGA1151/ Intel H170/ DDR4/ SATA3&USB3.1/ SATA Express/ A&GbE/ MicroATX Motherboard

SpecificationsMfr Part Number: CSM-H170M-A PROCPU: LGA1151Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron ProcessorsChipset: Intel H170Memory: 4x DDR4-2133 DIMM Slots, Dual Channel, ECC, Un-buffered, Max Capacity of 64GBSlots: 2x PCI-Express 3.0 x16 Slots (one runs at x4), 2x PCI-Express 3.0 x1 SlotsSATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10; 1x SATA Express Port (PCI-Express 3.0 x2)Audio: Realtek ALC892 7.1-Channel High Definition Audio CODECLAN: Realtek RTL8111H Gigabit Ethernet ControllerPorts: 8x USB 3.1 Ports (4 Gen1 rear, 4 Gen1 via headers), 4x USB 2.0 Ports (2 rear, 2 via header), 1x PS/2 Keyboard/Mouse Combo Port, 1x VGA Port, 1x HDMI Port, 1x DVI-D Port, 1x RJ45 LAN Port, 1x Optical S/PDIF OUT, Audio I/O JacksPower Connector: 1x 24pin ATX Main Power Connector, 1x 8pin ATX 12V Power ConnectorForm Factor: MicroATX, 9.6 x 9.6 inch / 24.4 x 24.4 cm

• Product images are for illustrative purposes only therefore the delivered product may vary from the one shown above.
• In some cases, packaging may differ from OEM/original retail box. For bulk orders that are packaged together, product manuals or CDs may not always be available for each item.
• The shipping cost added at the checkout is a general estimate which is subject to change depending on size/weight/quantity of ordered goods.
• Orders that contain end of life (EOL) products that are no longer in production may be replaced by a compatible product with the same FRU number offering same functionality.
• Refurbished printers may not have full ink cartridges or laser toners.
• Once an order is processed at our warehouse, it cannot be cancelled. A returned order will likely incur a restocking fee. See RMA page for details about restocking fees.
• Please note if you are concerned about any of the above conditions or have any questions, we highly recommend that you contact us on sales@ithardwaregroup.co.uk or call 020 37908599 before placing an order
