Design |
---|
Product type | Notebook |
Form factor | Clamshell |
Colour of product | Black |
Display |
---|
LED backlight | Yes |
Touchscreen | No |
Display resolution | 1920 x 1080 pixels |
Display diagonal | 14" |
Processor |
---|
Stepping | D1 |
Processor operating modes | 64-bit |
Processor lithography | 14 nm |
Processor codename | Skylake |
Bus type | OPI |
Tjunction | 100 °C |
Thermal Design Power (TDP) | 15 W |
Processor series | Intel Core i7-6600 Mobile series |
PCI Express slots version | 3.0 |
PCI Express configurations | 1x4,4x1 |
Maximum number of PCI Express lanes | 12 |
ECC supported by processor | No |
Configurable TDP-down frequency | 800 MHz |
Processor cache type | Smart Cache |
Conflict Free processor | Yes |
Processor cache | 4 MB |
Processor frequency | 2.6 GHz |
Processor model | i7-6600U |
Processor boost frequency | 3.4 GHz |
Processor cores | 2 |
Processor threads | 4 |
Processor socket | LGA 1356 (Socket B2) |
Processor family | 6th gen Intel® Core™ i7 |
Memory |
---|
Internal memory | 8 GB |
Internal memory type | DDR4-SDRAM |
Storage |
---|
Storage media | SSD |
Number of SSDs installed | 1 |
Solid-state drive capacity | 256 GB |
Card reader integrated | Yes |
Total storage capacity | 256 GB |
Graphics |
---|
Discrete graphics adapter | No |
On-board graphics adapter dynamic frequency (max) | 1050 MHz |
On-board graphics adapter base frequency | 300 MHz |
Maximum on-board graphics adapter memory | 32 GB |
On-board graphics adapter OpenGL version | 4.4 |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter ID | 1916 |
On-board graphics adapter | Yes |
On-board graphics adapter model | Intel® HD Graphics 520 |
Discrete graphics adapter model | Not available |
Camera |
---|
Front camera | Yes |
Optical drive |
---|
Optical drive type | No |
Networking |
---|
4G | No |
Wi-Fi | Yes |
Wi-Fi standards | IEEE 802.11ac |
Ethernet LAN | Yes |
Bluetooth | Yes |
3G | No |
Ports & interfaces |
---|
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 3 |
USB 3.1 (3.1 Gen 2) Type-C ports quantity | 1 |
Thunderbolt 3 ports quantity | 1 |
HDMI ports quantity | 1 |
DVI port | No |
Ethernet LAN (RJ-45) ports | 1 |
Docking connector | Yes |
Keyboard |
---|
Numeric keypad | No |
Software |
---|
Operating system installed | Windows 7 Professional |
Technical details |
---|
Intel® Small Business Advantage (Intel® SBA) | Yes |
Intel® Wireless Display (Intel® WiDi) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel Smart Connect Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Form factor | Clamshell |
Colour of product | Black |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Processor special features |
---|
Enhanced Intel SpeedStep Technology | Yes |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel® Insider™ | Yes |
Intel Clear Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® OS Guard | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Intel Stable Image Platform Program (SIPP) | Yes |
Intel Software Guard Extensions (Intel SGX) | 1 |
Intel® Secure Key | Yes |
Intel Flex Memory Access | Yes |
Intel Enhanced Halt State | Yes |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Thermal Monitoring Technologies | Yes |
Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
Processor package size | 42 |
Processor code | SR2F1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Idle States | Yes |
Graphics & IMC lithography | 14 nm |
Execute Disable Bit | Yes |
Embedded options available | Yes |
CPU configuration (max) | 1 |
Intel Stable Image Platform Program (SIPP) version | 1.00 |
Intel Smart Response Technology version | 1.00 |
Intel Small Business Advantage (SBA) version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | Yes |
Intel TSX-NI version | 1.00 |
Processor ARK ID | 88192 |
Intel® Small Business Advantage (Intel® SBA) | Yes |
Intel® Wireless Display (Intel® WiDi) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel Smart Connect Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Weight & dimensions |
---|
Width | 13" (331 mm) |
Depth | 8.93" (226.8 mm) |
Height (front) | 0.665" (1.69 cm) |
Height (rear) | 0.74" (1.88 cm) |
Weight | 2.91 lbs (1.32 kg) |
Other features |
---|
On-board graphics adapter | Yes |
