Motherboard |
---|
Motherboard form factor | UCFF |
Processor socket | BGA 1296 |
Number of processors supported | 1 |
Processor |
---|
Thermal Design Power (TDP) | 10 W |
L3 cache | 2 MB |
Built-in processor | Yes |
Processor model | J3455 |
Processor boost frequency | 2.30 GHz |
Processor threads | 4 |
Processor frequency | 1.50 GHz |
Processor socket | BGA 1296 |
Processor lithography | 14 nm |
Processor cores | 4 |
Processor family | Intel® Celeron® |
Number of processors supported | 1 |
Memory |
---|
Memory voltage | 1.35 V |
Memory slots type | SO-DIMM |
Number of memory slots | 2 |
Memory channels | Dual |
Memory bandwidth (max) | 14.9 GB/s |
ECC | No |
Supported memory types | DDR3L-SDRAM |
Supported memory clock speeds | 1600,1866 MHz |
Maximum internal memory | 8 GB |
Video |
---|
On-board graphics adapter | Yes |
Graphics adapter | HD Graphics 500 |
Graphics adapter family | Intel |
Storage |
---|
Supported storage drive types | HDD, SSD |
Storage drive sizes supported | 2.5" |
Storage drive interface | Serial ATA III |
Number of storage drives supported | 1 |
Compatible memory cards | SDXC |
Card reader integrated | Yes |
Graphics |
---|
On-board graphics adapter | Yes |
Graphics adapter | HD Graphics 500 |
Graphics adapter family | Intel |
Audio |
---|
Intel® High Definition Audio (Intel® HD Audio) | Yes |
Audio system | Realtek ALC283 HD Audio |
Audio output channels | 7.1 channels |
Networking |
---|
Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Bluetooth version | 4.2 |
Bluetooth | Yes |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Networking features | Gigabit Ethernet |
LAN controller | Realtek 8111HN |
Ports & interfaces |
---|
Consumer infrared headers | Yes |
Combo headphone/mic port | Yes |
Number of SATA III connectors | 1 |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 4 |
Internal USB 2.0 ports quantity | 2 |
HDMI version | 2.0 |
VGA (D-Sub) ports quantity | 1 |
USB 2.0 ports quantity | 2 |
S/PDIF out port | Yes |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Expansion slots |
---|
PCI Express slots version | 2.0 |
Design |
---|
Motherboard form factor | UCFF |
Product type | Mini PC barebone |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
On/off switch | Yes |
LED indicators | Power |
Colour of product | Black, Grey |
Product family | Intel NUC |
Product series | Intel NUC kit |
Product codename | Arches Canyon |
Performance |
---|
Intel Visual BIOS | Yes |
Intel Express BIOS update | Yes |
BIOS type | EEPROM |
Number of displays supported | 2 |
Trusted Platform Module (TPM) | No |
BIOS memory size | 64 MB |
Software |
---|
Operating system installed | No |
Compatible operating systems | Windows 10 Home, Windows 10 Pro |
Processor special features |
---|
Intel® Smart Response Technology | No |
Intel Smart Connect Technology | No |
Intel® Small Business Advantage (Intel® SBA) | No |
Intel® Secure Key | Yes |
Intel® OS Guard | No |
Intel Stable Image Platform Program (SIPP) | No |
Thermal Monitoring Technologies | Yes |
Intel® Wireless Display (Intel® WiDi) | No |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® Turbo Boost Technology | No |
Intel Trusted Execution Technology | No |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | No |
Intel® Insider™ | No |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel 64 | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Clear Video Technology | Yes |
Intel® vPro™ Technology | No |
Intel® Anti-Theft Technology (Intel® AT) | No |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® Virtualization Technology (Intel® VT) | VT-x |
Intel Rapid Storage Technology | No |
Embedded options available | No |
Colour |
---|
Colour of product | Black, Grey |
Technical details |
---|
BIOS type | EEPROM |
Intel® vPro™ Technology | No |
Intel® Anti-Theft Technology (Intel® AT) | No |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Intel® Virtualization Technology (Intel® VT) | VT-x |
Intel Rapid Storage Technology | No |
Intel® High Definition Audio (Intel® HD Audio) | Yes |
Embedded options available | No |
Trusted Platform Module (TPM) | No |
Quick start guide | Yes |
Processor cores | 4 |
BIOS memory size | 64 MB |
ARK ID | 95062 |
Packaging data |
---|
AC adapter included | Yes |
Indication |
---|
LED indicators | Power |
Management features |
---|
On/off switch | Yes |
Features |
---|
Number of displays supported | 2 |
Power |
---|
AC adapter output voltage | 12-19 |
Power supply type | External AC adapter |
Power supply | 65 W |
Operational conditions |
---|
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | 0 - 40 °C |
Certificates |
---|
Safety | IEC 60950-1, UL 60950-1, EN 60950-1, CAN/CSA-C22.2 No. 60950-1 |
Certification | RoHS, WEEE |
Weight & dimensions |
---|
Width | 4" (101.6 mm) |
Depth | 4" (101.6 mm) |
Height | 2.01" (51 mm) |
Packaging content |
---|
AC adapter included | Yes |
Quick start guide | Yes |
Other features |
---|
Embedded options available | No |
