Processor |
---|
Processor codename | Kaby Lake |
Processor cache | 6 MB |
Processor frequency | 3.8 GHz |
Processor model | i5-7600K |
Processor threads | 4 |
System bus rate | 8 GT/s |
Processor operating modes | 64-bit |
Compatible chipsets | Intel B150, Intel H110, Intel H170, Intel Q150, Intel Q170, Intel Z170 |
Processor boost frequency | 4.2 GHz |
Stepping | B0 |
Bus type | DMI3 |
Component for | PC |
Processor lithography | 14 nm |
Processor family | 7th gen Intel® Core™ i5 |
Processor cores | 4 |
Box | No |
Processor socket | LGA 1151 (Socket H4) |
Processor series | Intel Core i5-7600 Desktop Series |
Processor cache type | Smart Cache |
Memory |
---|
Maximum internal memory supported by processor | 64 GB |
Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
Memory channels supported by processor | Dual |
Memory voltage supported by processor | 1.35 V |
ECC supported by processor | No |
Graphics |
---|
On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
On-board graphics adapter 4K support | Yes |
On-board graphics adapter refresh rate at maximum resolution (HDMI) | 24 Hz |
On-board graphics adapter refresh rate at maximum resolution (DisplayPort) | 60 Hz |
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
Maximum on-board graphics adapter memory | 64 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
On-board graphics adapter DirectX version | 12.0 |
On-board graphics adapter OpenGL version | 4.4 |
On-board graphics adapter model | Intel HD Graphics 630 |
On-board graphics adapter | Yes |
On-board graphics adapter dynamic frequency (max) | 1150 MHz |
On-board graphics adapter base frequency | 350 MHz |
Technical details |
---|
Intel Stable Image Platform Program (SIPP) | No |
Thermal solution specification | PCG 2015C |
Intel TSX-NI | Yes |
Intel® Secure Key | Yes |
Thermal Monitoring Technologies | Yes |
Intel® vPro™ Technology | No |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Enhanced Intel SpeedStep Technology | Yes |
PCI Express slots version | 3.0 |
PCI Express configurations | 1x16,1x8+2x4,2x8 |
Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
Scalability | 1S |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Enhanced Halt State | Yes |
Embedded options available | No |
CPU configuration (max) | 1 |
Processor code | SR32V |
Product type | 4 |
Processor cache | 6144 KB |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Video decoding | Yes |
Thermal Design Power (TDP) | 91 W |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Status | Launched |
Processor series | Intel Core i5-7600 Desktop Series |
Launch date | Q1'17 |
Intel Virtualization Technology (VT-x) | Yes |
Processor cache type | Smart Cache |
Product family | 7th Generation Intel Core i5 Processors |
Features |
---|
On-board graphics adapter ID | 5912 |
Maximum number of PCI Express lanes | 16 |
Thermal Design Power (TDP) | 91 W |
Processor package size | 37.5 x 37.5 |
Processor ARK ID | 97144 |
Thermal solution specification | PCG 2015C |
Thermal Monitoring Technologies | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
PCI Express slots version | 3.0 |
PCI Express configurations | 1x16,1x8+2x4,2x8 |
Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
Scalability | 1S |
Embedded options available | No |
CPU configuration (max) | 1 |
Processor code | SR32V |
Processor special features |
---|
Intel Clear Video Technology | Yes |
Intel Software Guard Extensions (Intel SGX) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Conflict Free processor | Yes |
Intel® Optane™ Memory Ready | Yes |
Intel® OS Guard | Yes |
Intel Stable Image Platform Program (SIPP) | No |
Intel TSX-NI | Yes |
Intel® Secure Key | Yes |
Intel® vPro™ Technology | No |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Enhanced Halt State | Yes |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Operational conditions |
---|
Tjunction | 100 °C |
Other features |
---|
Video decoding | Yes |
Maximum internal memory | 65536 MB |
CPU configuration (max) | 1 |
Processor code | SR32V |
