HPE ProLiant DL20 Gen9 Servers - 830698-S01

Brand: HPE

(No reviews yet) Write a Review

Part Number #: 830698-S01
Availability:: In Stock

MSRP: £1,988.80

£1,657.33

Inc. VAT

MSRP: £1,657.33

£1,381.11

Ex. VAT

— You save £331.47

Current Stock:

Quantity:

Get Bulk Pricing

Don't like the price? Make an offer!

Description
Read Before Ordering

Description

Main Specifications

Product Description	HPE ProLiant DL20 Gen9 - Xeon E3-1200 series E3-1240V5 3.5 GHz - 8 GB - 0 GB
Type	Server - rack-mountable
Server Scalability	1-way
Processor	1 x Intel Xeon E3-1200 series E3-1240V5 / 3.5 GHz ( Quad-Core )
Cache Memory	8 MB L3 cache
RAM	8 GB (installed) / 64 GB (max) - DDR4 SDRAM - 2133 MHz
Storage Controller	RAID ( SATA 6Gb/s ) - PCIe x4 ( HP Dynamic Smart Array B140i )
Server Storage Bays	Hot-swap 3.5"
Hard Drive	No HDD
Networking	GigE
Power	AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH)	17.2 in x 15 in x 1.7 in
Manufacturer Selling Program	HP Smart Buy
Manufacturer Warranty	1 year warranty

Extended Specifications

General

Type	Server
Product Form Factor	Rack-mountable
Embedded Security	Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability	1-way
Front Accessible Bays Qty	2
Hot-Swap Bays Qty	2

Processor / Chipset

CPU	Intel Xeon E3-1200 series E3-1240V5 / 3.5 GHz
Number of Cores	Quad-Core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Upgradable
Chipset Type	Intel C232

Cache Memory

Installed Size

L3 cache - 8 MB

RAM

Installed Size	8 GB / 64 GB (max)
Technology	DDR4 SDRAM
Memory Speed	2133 MHz
Form Factor	DIMM 288-pin
Features	Unbuffered, dual channel memory architecture
Configuration Features	1 x 8 GB

Hard Drive

Type

No HDD

Storage Controller

Type	1 x RAID - PCIe x4
Controller Interface Type	SATA 6Gb/s
Storage Controller Name	HP Dynamic Smart Array B140i
Channel Qty	10
RAID Level	RAID 0, RAID 1, RAID 5, RAID 10

Monitor

Monitor Type

None.

Networking

Interface (Bus) Type	PCI Express x2
Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	HP NC332i
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller	Integrated Lights-Out 4
Features	Wake on LAN (WoL), PXE support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion / Connectivity

Bays	2 (total) / 2 (free) x external 3.5" LFF
Slots	4 (total) / 3 (free) x DIMM 288-pin ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card ¦ 1 (total) / 1 (free) x FlexibleLOM
Interfaces	1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 ( 2 in front ) ¦ 3 x USB 3.0 ( 2 rear )

Miscellaneous

Included Accessories	HPE Short Friction Rail kit
Manufacturer Selling Program	HP Smart Buy

Power

Device Type	Power supply
Nominal Voltage	AC 120/230 V ( 50/60 Hz )
Power Provided	290 Watt

Operating System / Software

OS Certified

SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux

Manufacturer Warranty

Service & Support	1 year warranty
Service & Support Details	Limited warranty - 1 year

Dimensions & Weight

Width	17.2 in
Depth	15 in
Height	1.7 in

Environmental Parameters

Min Operating Temperature	50 °F
Max Operating Temperature	95 °F
Humidity Range Operating	8 - 90%
