HPE ProLiant DL20 Gen9 Entry Servers - 829889-B21

Brand: HPE

(No reviews yet) Write a Review

Part Number #: 829889-B21
Availability:: In Stock

MSRP: £1,288.10

£1,073.42

Inc. VAT

MSRP: £1,073.42

£894.52

Ex. VAT

— You save £214.68

Current Stock:

Quantity:

Get Bulk Pricing

Don't like the price? Make an offer!

Description
Read Before Ordering

Description

Main Specifications

Product Description	HPE ProLiant DL20 Gen9 Entry - Pentium G4400 3.3 GHz - 4 GB - 0 GB
Type	Server - rack-mountable
Height (Rack Units)	1U
Server Scalability	1-way
Processor	1 x Intel Pentium G4400 / 3.3 GHz ( Dual-Core )
Processor Socket	LGA1151 Socket
Cache Memory	3 MB
Cache Per Processor	3 MB
RAM	4 GB (installed) / 64 GB (max) - DDR4 SDRAM - ECC - 2133 MHz - PC4-17000
Storage Controller	RAID ( SATA 6Gb/s ) - PCIe x4 ( HP Dynamic Smart Array B140i )
Server Storage Bays	Non-hot-swap 3.5"
Hard Drive	No HDD
Networking	GigE
Power	AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH)	17.1 in x 15 in x 1.7 in
Manufacturer Warranty	3 years warranty - on-site ( 1st year only )

Extended Specifications

General

Type	Server
Product Form Factor	Rack-mountable - 1U
Embedded Security	Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability	1-way
Internal Bays Qty	2
Front Accessible Bays Qty	1

Processor / Chipset

CPU	Intel Pentium G4400 / 3.3 GHz
Number of Cores	Dual-Core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Upgradable
CPU Socket	LGA1151 Socket
Chipset Type	Intel C232

Cache Memory

Installed Size	3 MB
Cache Per Processor	3 MB

RAM

Installed Size	4 GB / 64 GB (max)
Technology	DDR4 SDRAM - ECC
Memory Speed	2133 MHz
Memory Specification Compliance	PC4-17000
Form Factor	DIMM 288-pin
Features	Unbuffered, dual channel memory architecture
Configuration Features	1 x 4 GB

Hard Drive

Type

No HDD

Storage Controller

Type	1 x RAID - PCIe x4
Controller Interface Type	SATA 6Gb/s
Storage Controller Name	HP Dynamic Smart Array B140i
Channel Qty	10
RAID Level	RAID 0, RAID 1, RAID 5, RAID 10

Monitor

Monitor Type

None.

Networking

Interface (Bus) Type	PCI Express x2
Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	HP NC332i
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller	Integrated Lights-Out 4
Features	Wake on LAN (WoL), PXE support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion / Connectivity

Bays	1 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 2 (free) x internal 3.5" LFF
Slots	4 (total) / 3 (free) x DIMM 288-pin ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card ¦ 1 (total) / 1 (free) x FlexibleLOM
Interfaces	1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 ( 2 in front ) ¦ 3 x USB 3.0 ( 2 rear, 1 internal )

Miscellaneous

Included Accessories	HPE Short Friction Rail kit
Compliant Standards	ACPI 2.0b, FCC Class A certified, CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, GB 9254, ASHRAE, CNS 13438

Power

Device Type	Power supply
Nominal Voltage	AC 120/230 V ( 50/60 Hz )
Power Provided	290 Watt
Efficiency	92%

Operating System / Software

OS Certified

SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux

Manufacturer Warranty

Service & Support	3 years warranty
Service & Support Details	Limited warranty - parts - 3 years ¦ Limited warranty - parts and labor - 1 year - on-site

Dimensions & Weight

Width	17.1 in
Depth	15 in
Height	1.7 in

Environmental Parameters

Min Operating Temperature	50 °F
Max Operating Temperature	95 °F
Humidity Range Operating	8 - 90%
