HPE ProLiant DL20 Gen9 Entry Servers - 829889-B21

Brand:
(No reviews yet) Write a Review
Part Number #
829889-B21
Availability:
In Stock
MSRP: £1,288.10
£1,073.42
Inc. VAT
MSRP: £1,073.42
£894.52
Ex. VAT
— You save £214.68
Get Bulk Pricing
Don't like the price? Make an offer!

Description

Main Specifications

Product Description HPE ProLiant DL20 Gen9 Entry - Pentium G4400 3.3 GHz - 4 GB - 0 GB
Type Server - rack-mountable
Height (Rack Units) 1U
Server Scalability 1-way
Processor 1 x Intel Pentium G4400 / 3.3 GHz ( Dual-Core )
Processor Socket LGA1151 Socket
Cache Memory 3 MB
Cache Per Processor 3 MB
RAM 4 GB (installed) / 64 GB (max) - DDR4 SDRAM - ECC - 2133 MHz - PC4-17000
Storage Controller RAID ( SATA 6Gb/s ) - PCIe x4 ( HP Dynamic Smart Array B140i )
Server Storage Bays Non-hot-swap 3.5"
Hard Drive No HDD
Networking GigE
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 17.1 in x 15 in x 1.7 in
Manufacturer Warranty 3 years warranty - on-site ( 1st year only )



Extended Specifications

General
Type Server
Product Form Factor Rack-mountable - 1U
Embedded Security Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability 1-way
Internal Bays Qty 2
Front Accessible Bays Qty 1
Processor / Chipset
CPU Intel Pentium G4400 / 3.3 GHz
Number of Cores Dual-Core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
CPU Socket LGA1151 Socket
Chipset Type Intel C232
Cache Memory
Installed Size 3 MB
Cache Per Processor 3 MB
RAM
Installed Size 4 GB / 64 GB (max)
Technology DDR4 SDRAM - ECC
Memory Speed 2133 MHz
Memory Specification Compliance PC4-17000
Form Factor DIMM 288-pin
Features Unbuffered, dual channel memory architecture
Configuration Features 1 x 4 GB
Hard Drive
Type No HDD
Storage Controller
Type 1 x RAID - PCIe x4
Controller Interface Type SATA 6Gb/s
Storage Controller Name HP Dynamic Smart Array B140i
Channel Qty 10
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Monitor
Monitor Type None.
Networking
Interface (Bus) Type PCI Express x2
Ethernet Ports 2 x Gigabit Ethernet
Ethernet Controller HP NC332i
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL), PXE support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays 1 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 2 (free) x internal 3.5" LFF
Slots 4 (total) / 3 (free) x DIMM 288-pin ¦ 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card ¦ 1 (total) / 1 (free) x FlexibleLOM
Interfaces 1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 ( 2 in front ) ¦ 3 x USB 3.0 ( 2 rear, 1 internal )
Miscellaneous
Included Accessories HPE Short Friction Rail kit
Compliant Standards ACPI 2.0b, FCC Class A certified, CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, GB 9254, ASHRAE, CNS 13438
Power
Device Type Power supply
Nominal Voltage AC 120/230 V ( 50/60 Hz )
Power Provided 290 Watt
Efficiency 92%
Operating System / Software
OS Certified SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Manufacturer Warranty
Service & Support 3 years warranty
Service & Support Details Limited warranty - parts - 3 years ¦ Limited warranty - parts and labor - 1 year - on-site
Dimensions & Weight
Width 17.1 in
Depth 15 in
Height 1.7 in
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90%
