Design |
---|
Intel segment tagging | Enterprise |
Product type | Ultrabook |
Form factor | Clamshell |
Colour of product | Silver |
Display |
---|
LED backlight | Yes |
Aspect ratio | 16:9 |
Touchscreen | No |
Display resolution | 2560 x 1440 pixels |
Display diagonal | 14" |
Processor |
---|
Stepping | D1 |
Processor operating modes | 64-bit |
Processor lithography | 14 nm |
Processor codename | Skylake |
Bus type | OPI |
Tjunction | 100 °C |
Thermal Design Power (TDP) | 15 W |
Processor series | Intel Core i7-6600 Mobile series |
PCI Express slots version | 3.0 |
PCI Express configurations | 1x4,4x1 |
Maximum number of PCI Express lanes | 12 |
Configurable TDP-down | 7.5 W |
ECC supported by processor | No |
Configurable TDP-down frequency | 800 MHz |
Processor cache type | Smart Cache |
Conflict Free processor | Yes |
Processor cache | 4 MB |
Processor frequency | 2.6 GHz |
Processor model | i7-6600U |
Processor boost frequency | 3.4 GHz |
Processor cores | 2 |
Processor threads | 4 |
Processor socket | LGA 1356 (Socket B2) |
Processor family | 6th gen Intel® Core™ i7 |
Memory |
---|
Memory form factor | SO-DIMM |
Internal memory | 8 GB |
Memory layout (slots x size) | 1 x 8 GB |
Internal memory type | DDR4-SDRAM |
Memory clock speed | 2133 MHz |
Memory slots | 2x SO-DIMM |
Maximum internal memory | 16 GB |
Storage |
---|
SSD form factor | M.2 |
Storage media | SSD |
Number of SSDs installed | 1 |
Solid-state drive capacity | 512 GB |
Solid-state drive interface | Serial ATA |
Card reader integrated | Yes |
Compatible memory cards | SD,SDHC,SDXC |
Total storage capacity | 512 GB |
Video |
---|
Graphics adapter Open GL support | Yes |
Graphics |
---|
Discrete graphics adapter | No |
On-board graphics adapter dynamic frequency (max) | 1050 MHz |
On-board graphics adapter base frequency | 300 MHz |
Maximum on-board graphics adapter memory | 32 GB |
On-board graphics adapter OpenGL version | 4.4 |
On-board graphics adapter DirectX version | 12 |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter ID | 1916 |
On-board graphics adapter family | Intel® HD Graphics |
On-board graphics adapter | Yes |
On-board graphics adapter model | Intel® HD Graphics 520 |
Discrete graphics adapter model | Not available |
Graphics adapter Open GL support | Yes |
Audio |
---|
Number of built-in speakers | 2 |
Speakers manufacturer | Bang & Olufsen |
Built-in microphone | Yes |
Camera |
---|
Front camera | Yes |
Optical drive |
---|
Optical drive type | No |
Networking |
---|
4G | No |
Wi-Fi | Yes |
Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Bluetooth | Yes |
Bluetooth version | 4.2 |
3G | No |
Ports & interfaces |
---|
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
DisplayPorts quantity | 1 |
DVI port | No |
Ethernet LAN (RJ-45) ports | 1 |
Combo headphone/mic port | Yes |
Docking connector | Yes |
DC-in jack | Yes |
Keyboard |
---|
Pointing device | Touchpad |
Numeric keypad | No |
Spill resistant keyboard | Yes |
Keyboard backlit | Yes |
Software |
---|
Operating system architecture | 64-bit |
Optional operating system supplied | Windows 10 Pro |
Drivers included | Yes |
Operating system installed | Windows 7 Professional |
Technical details |
---|
Power cord included | Yes |
Intel® Small Business Advantage (Intel® SBA) | Yes |
Intel® Wireless Display (Intel® WiDi) | Yes |
Intel® vPro™ Technology | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel Smart Connect Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Form factor | Clamshell |
Colour of product | Silver |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Processor special features |
---|
Enhanced Intel SpeedStep Technology | Yes |
Intel® Built-in Visuals Technology | Yes |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel® Insider™ | Yes |
Intel HD Graphics | Yes |
Intel Clear Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® OS Guard | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Intel Stable Image Platform Program (SIPP) | Yes |
Intel Software Guard Extensions (Intel SGX) | 1 |
Intel® Smart Cache | Yes |
Intel® Secure Key | Yes |
Intel Flex Memory Access | Yes |
Intel Enhanced Halt State | Yes |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Thermal Monitoring Technologies | Yes |
Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
Processor package size | 42 |
Processor code | SR2F1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Idle States | Yes |
Graphics & IMC lithography | 14 nm |
Execute Disable Bit | Yes |
Embedded options available | Yes |
CPU configuration (max) | 1 |
Intel Stable Image Platform Program (SIPP) version | 1.00 |
Intel Smart Response Technology version | 1.00 |
Intel Small Business Advantage (SBA) version | 1.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | Yes |
Intel TSX-NI version | 1.00 |
Processor ARK ID | 88192 |
Intel® Small Business Advantage (Intel® SBA) | Yes |
Intel® Wireless Display (Intel® WiDi) | Yes |
Intel® vPro™ Technology | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel Smart Connect Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Battery |
---|
Battery technology | Lithium-Ion (Li-Ion) |
Number of battery cells | 3 |
Battery capacity (Watt hours) | 46 Wh |
Security |
---|
Trusted Platform Module (TPM) | Yes |
Cable lock slot | Yes |
Certificates |
---|
Energy Star certified | Yes |
Weight & dimensions |
---|
Width | 13.3" (338 mm) |
Depth | 9.33" (237 mm) |
Height | 0.744" (18.9 mm) |
Weight | 3.26 lbs (1.48 kg) |
Packaging data |
---|
Power cord included | Yes |
Warranty card | Yes |
Quick start guide | Yes |
Manual | Yes |
AC adapter included | Yes |
Packaging content |
---|
Power cord included | Yes |
Warranty card | Yes |
Quick start guide | Yes |
Manual | Yes |
AC adapter included | Yes |
Other features |
---|
On-board graphics adapter | Yes |
