HP 2530-24G Switch Switch 24Ports Managed Desktop-Rack-mountable
Brand: HP
Write a Review
×
HP
HP 2530-24G Switch Switch 24Ports Managed Desktop-Rack-mountable
- Part Number #
- J9776A
- Availability:
- In Stock

Description
General Specifications
Manufacturer | HP |
Manufacturer | J9776A |
Manufacturer UPC # | 0886112458515 |
Product Description | HP 2530-24G Switch - Switch - managed - 24 x 10/100/1000 + 4 x Gigabit SFP - desktop, rack-mountable, wall-mountable |
Device Type | Switch - 24 ports - managed |
Enclosure Type | Desktop, rack-mountable, wall-mountable 1U |
Interfaces | Gigabit Ethernet |
Ports | 24 x 10/100/1000 + 4 x Gigabit SFP |
Performance | Throughput : 41.6 Mpps Switching capacity : $93 ($93 (56 Gbp))s |
MAC Address Table Size | 16000 entries |
Jumbo Frame Support | 9220 |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI |
Features | Flow control, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Multicast Suppression, STP Root Guard, LLDP support, dual firmware images, Class of Service (CoS), Generic Attribute Registration Protocol (GARP) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az |
Power | AC 120/230 V ( 50/60 Hz ) |
Approximate Dimensions (WxDxH) | 17.4 in x 10 in x 1.8 in |
Approximate Weight | 6.1 lbs |
Localization | English / United States |
Brief Overview
- Wall-mountable 1U
- Remote Management Protocol
- Gigabit Ethernet
- 24 ports
- VLAN support
- umbo Frame Support
The HP 2530 Switch Series consists of 12 fully managed Layer 2 edge switches that deliver cost-effective, reliable, secure, and easy-to-use connectivity to business networks. Designed for entry-level to midsize enterprise networks, these Gigabit and Fast Ethernet switches deliver full Layer 2 capabilities with optional PoE+, enhanced access security, traffic prioritization, and IPv6 host support. The HP 2530 Switch Series offers uplink flexibility with four Gigabit Ethernet uplinks on all 24- and 48-port models. Gigabit Ethernet uplinks are four small form-factor pluggable (SFP) slots for fiber connectivity on the 24- and 48-port Gigabit Ethernet models. The Fast Ethernet 24- and 48-port models have two SFPs and two RJ-45 Gigabit uplinks. The compact and fanless 8-port switches offer additional flexibility with two dual-personality ports that can be used as either RJ-45 Gigabit Ethernet or SFP ports. For customers implementing Power over Ethernet for voice, video, or wireless deployments, the HP 2530 PoE+ switches are IEEE 802.3af and IEEE 802.3at compliant with up to 30 W per port. The switch series is easy to use, deploy, and manage via SNMP, CLI, and Web GUI. It offers flexible wall, table, and rack mounting; quiet operation with fanless and variable speed fan models; and improved power savings, with features such as IEEE 802.3 az (Energy Efficient Ethernet). These switches include a lifetime warranty, as well as all software releases and technical phone support.
