GIGABYTE GA-Z270-HD3 LGA1151/ Intel Z270/ DDR4/ Quad CrossFireX/ SATA3&USB3.1/ M.2&SATA Express/ A&GbE/ ATX Motherboard

Specifications

• Mfr Part Number: GA-Z270-HD3

• CPU: LGA1151
  • Supports 7th/ 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors

• Chipset: Intel Z270 Express

• Memory: 4x DDR4-3866(OC)/ 3800(OC)/ 3733(OC)/ 3666(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2666(OC)/ 2400/ 2133 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 64GB

• Slots: 3x PCI-Express 3.0 x16 Slots (two run at x4), 2x PCI-Express 3.0 x1 Slots, 1x PCI Slot

• Multi-Graphics: Supports AMD Quad-GPU and 2-Way CrossFireX Technology

• Storage:
  • SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10; 1x SATA Express Port

  • M.2: 1x M.2 Port (M key), Support type 2242/ 2260/ 2280/ 22110 SATA & PCIe x4/x2 SSD

• Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC

• LAN: Intel Gigabit Ethernet Controller
• Ports: 8x USB 3.1 Gen1 Ports (4 rear, 4 via headers), 6x USB 2.0/1.1 Ports (2 rear, 4 via headers), 1x PS/2 Keyboad/Mouse Port, 1x VGA Port, 1x HDMI Port, 1x DVI-D Port, 1x RJ45 LAN Port, Audio I/O Jacks

• Power Connector: 1x 24-pin ATX Main Power Connector, 1x 8-pin ATX 12V Power Connector

• Form Factor: ATX, 30.5 x 22.5 cm
