GIGABYTE GA-Q87N LGA1150/ Intel Q87/ DDR3/ SATA3&USB3.0/ A&GbE/ Mini-ITX Motherboard

Specifications

• Mfr Part Number: GA-Q87N
• CPU: LGA1150
  • Supports 4th Generation Intel Core i7/ i5/ i3, Pentium, Celeron Processors
• Chipset: Intel Q87 Express
• Memory: 2x DDR3-1600/1333 DIMM Slots, Dual Channel, Non-ECC, Max Capacity of 16GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x MSMP Slot for the wireless communication module or an mSATA device
• SATA: 4x SATA3 Ports, 1x mSATA Port, Support RAID 0, 1, 5, 10
• Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC
• LAN: Intel Gigabit Ethernet Controller
• Ports: 6x USB 3.0 Ports (4 rear, 2 via header), 4x USB 2.0 Ports (2 rear, 2 via header), 1 x PS/2 Keyboard/Mouse Combo Port, 1x DisplayPort, 1x DVI-I Port, 1x DVI-D Port, 1x eSATA Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Main Power Connector, 1x 4pin ATX 12V Power Connector
• Form Factor: Mini-ITX, 17.0 x 17.0 cm
