GIGABYTE GA-H110N LGA1151/ Intel H110/ DDR4/ SATA3&USB3.0/ M.2/ A&GbE/ Mini-ITX Motherboard

Specifications

• Mfr Part Number: GA-H110N
• CPU: LGA1151
  • Supports Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
• Chipset: Intel H110 Express
• Memory: 2x DDR4-2133 DIMM Slots, Dual Channel, ECC, Non-ECC, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot
• Storage:
  • SATA: 3x SATA3 Ports
  • M.2: 1x M.2 Port (type 2260/2280), Support SATA & PCI-Express SSD
• Audio: Realtek ALC887 7.1-Channel High Definition Audio CODEC, Supports S/PDIF Output
• LAN: Realtek Gigabit Ethernet Controller
• Ports: 4x USB 3.0/2.0 Ports (2 rear, 2 via header), 6x USB 2.0/1.1 Ports (4 rear, 2 via header), 1 x PS/2 Keyboard/Mouse Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Main Power Connector, 1x 4pin ATX 12V Power Connector
• Form Factor: Mini-ITX, 17.0 x 17.0cm
