| Scanning |
|---|
| Black/white scanning colour modes | Grayscale, Monochrome |
| Maximum scan size | 12 x 17" (304.8 x 431.8 mm) |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Output colour depth | 24 bit |
| Film scanning | No |
| Optical density (Dmax) | 60 |
| ADF scan speed (b/w, A4) | 60 ppm |
| Duplex ADF scan speed (b/w, A4) | 120 ipm |
| Duplex ADF scan speed (colour, A4) | 120 ipm |
| Sensor type | Dual CCD |
| Light source | White LED (4x) |
| Design |
|---|
| Built-in display | Yes |
| Scanner type | ADF scanner |
| Colour of product | Grey, White |
| Performance |
|---|
| Sensor type | Dual CCD |
| Light source | White LED (4x) |
| Scan drivers | ISIS,TWAIN |
| Input capacity |
|---|
| Auto document feeder (ADF) input capacity | 100 sheets |
| Paper handling |
|---|
| Media thickness (min) | 0.0551" (1.4 mm) |
| Scanning media types supported | Plain paper |
| Maximum scan area (ADF) | 12 x 17" (304.8 x 431.8 mm) |
| Minimum scan area (ADF) | 2 x 2.72" (50.8 x 69 mm) |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Multi feed detection | Yes |
| ISO A-series sizes (A0...A9) | A1,A2,A3,A4,A8 |
| Ports & interfaces |
|---|
| Standard interfaces | USB 3.0 |
| Software |
|---|
| Bundled software | PaperStream IP, PaperStream Capture, Software Operation Panel, Error Recovery Guide, Scanner Central Admin tools, ScanSnap Manager, Scan to Microsoft SharePoint, ABBYY FineReader, 2D barcode for PaperStream |
| Scan drivers | ISIS,TWAIN |
| Drivers included | Yes |
| Power |
|---|
| Power consumption (typical) | 36 W |
| Power consumption (standby) | 0.35 W |
| Power consumption (off) | 0.35 W |
| Input voltage | 100-240 |
| Power supply type | AC |
| Power consumption (PowerSave) | 1.4 W |
| Media formats |
|---|
| ISO A-series sizes (A0...A9) | A1,A2,A3,A4,A8 |
| Technical details |
|---|
| Black/white scanning colour modes | Grayscale, Monochrome |
| Media thickness (min) | 0.0551" (1.4 mm) |
| Scanner type | ADF scanner |
| Colour of product | Grey, White |
| Operational conditions |
|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Certificates |
|---|
| RoHS compliance | Yes |
| Energy Star certified | Yes |
| Weight & dimensions |
|---|
| Width | 15" (380 mm) |
| Depth | 8.23" (209 mm) |
| Height | 6.61" (168 mm) |
| Weight | 16.8 lbs (7.6 kg) |
| Packaging content |
|---|
| Quick start guide | Yes |
| Cables included | AC, USB |
| Bundled software | PaperStream IP, PaperStream Capture, Software Operation Panel, Error Recovery Guide, Scanner Central Admin tools, ScanSnap Manager, Scan to Microsoft SharePoint, ABBYY FineReader, 2D barcode for PaperStream |
| Drivers included | Yes |
| Other features |
|---|
| Scanner type | ADF scanner |
