Design |
---|
Product type | Notebook |
Form factor | Clamshell |
Colour of product | Black |
Display |
---|
HD type | HD |
Display surface | Matt |
LED backlight | Yes |
Aspect ratio | 16:9 |
Display brightness | 200 cd/m² |
Pixel pitch | 0.00797 x 0.00797" (0.203 x 0.203 mm) |
Touchscreen | No |
Display resolution | 1366 x 768 pixels |
Display diagonal | 12.5" |
Processor |
---|
Stepping | Y0 |
Processor operating modes | 64-bit |
Processor lithography | 14 nm |
Processor codename | Kaby Lake R |
Bus type | OPI |
Tjunction | 100 °C |
Thermal Design Power (TDP) | 15 W |
PCI Express slots version | 3.0 |
PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
Maximum number of PCI Express lanes | 12 |
ECC supported by processor | No |
Configurable TDP-down frequency | 800 MHz |
Processor cache type | Smart Cache |
Conflict Free processor | Yes |
Processor cache | 6 MB |
Processor frequency | 1.70 GHz |
Processor model | i5-8350U |
Processor boost frequency | 3.60 GHz |
Processor cores | 4 |
Processor threads | 8 |
System bus rate | 4 GT/s |
Processor socket | BGA 1356 |
Processor family | 8th gen Intel® Core™ i5 |
Memory |
---|
Memory form factor | SO-DIMM |
Internal memory | 8 GB |
Internal memory type | DDR4-SDRAM |
Memory slots | 1x SO-DIMM |
Maximum internal memory | 16 GB |
Maximum internal memory (64-bit) | 16 GB |
Storage |
---|
Storage media | SSD |
Number of SSDs installed | 1 |
Solid-state drive capacity | 256 GB |
Card reader integrated | Yes |
Compatible memory cards | SD |
Total storage capacity | 256 GB |
Graphics |
---|
Discrete graphics adapter | No |
On-board graphics adapter dynamic frequency (max) | 1100 MHz |
On-board graphics adapter base frequency | 300 MHz |
Maximum on-board graphics adapter memory | 32 GB |
On-board graphics adapter OpenGL version | 4.4 |
On-board graphics adapter DirectX version | 12.0 |
Number of displays supported (on-board graphics) | 3 |
On-board graphics adapter ID | 0x5917 |
On-board graphics adapter | Yes |
On-board graphics adapter model | Intel UHD Graphics 620 |
Discrete graphics adapter model | Not available |
Audio |
---|
Audio chip | Realtek ALC3246 |
Number of built-in speakers | 2 |
Speaker power | 2 W |
Built-in microphone | Yes |
Camera |
---|
Front camera signal format | 720p |
Front camera | Yes |
Front camera resolution (numeric) | 0.92 MP |
Front camera resolution | 1280 x 720 pixels |
Video capturing speed | 30 fps |
Front camera HD type | HD |
Optical drive |
---|
Optical drive type | No |
Networking |
---|
4G | No |
Wi-Fi | Yes |
Wi-Fi standards | IEEE 802.11ac |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Bluetooth | Yes |
Bluetooth version | 4.2 |
3G | No |
Ports & interfaces |
---|
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
USB Type-C DisplayPort Alternate Mode | Yes |
HDMI ports quantity | 1 |
HDMI version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
Combo headphone/mic port | Yes |
DC-in jack | Yes |
SmartCard slot | Yes |
PowerShare | Yes |
Number of USB ports with PowerShare support | 1 |
Expansion slots |
---|
SmartCard slot | Yes |
Performance |
---|
SmartCard slot | Yes |
Keyboard |
---|
Pointing device | Touchpad |
Numeric keypad | No |
Windows keys | Yes |
Keyboard backlit | Yes |
Software |
---|
Operating system architecture | 64-bit |
Drivers included | Yes |
Operating system installed | Windows 10 Pro |
Technical details |
---|
Power cord included | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Form factor | Clamshell |
Colour of product | Black |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Processor special features |
---|
Enhanced Intel SpeedStep Technology | Yes |
Intel® Quick Sync Video Technology | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel Clear Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® OS Guard | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Trusted Execution Technology | Yes |
Intel Software Guard Extensions (Intel SGX) | Yes |
Intel® Secure Key | Yes |
Intel Flex Memory Access | Yes |
Intel Enhanced Halt State | Yes |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Thermal Monitoring Technologies | Yes |
Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
Processor package size | 42 x 24 |
Processor code | SR3L9 |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Embedded options available | No |
CPU configuration (max) | 1 |
Intel Virtualization Technology (VT-x) | Yes |
Processor ARK ID | 124969 |
Intel® Turbo Boost Technology | 2.0 |
Intel® Smart Response Technology | Yes |
Intel® My WiFi Technology (Intel® MWT) | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Power |
---|
AC adapter frequency | 50/60 Hz |
AC adapter input voltage | 100 - 240 V |
AC adapter output voltage | 19.5 V |
Security |
---|
Password protection | Yes |
Cable lock slot type | Noble |
Trusted Platform Module (TPM) | Yes |
Cable lock slot | Yes |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 60 °C |
Storage temperature (T-T) | -51 - 71 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 95% |
Operating altitude | -598.4 - 120000" (-15.2 - 3048 m) |
Non-operating altitude | -600 - 420000" (-15.2 - 10668 m) |
Certificates |
---|
Energy Star certified | Yes |
Weight & dimensions |
---|
Width | 12" (304.8 mm) |
Depth | 8.19" (207.9 mm) |
Height (front) | 0.65" (1.65 cm) |
Height (rear) | 0.65" (1.65 cm) |
Weight | 2.62 lbs (1.19 kg) |
Packaging data |
---|
Power cord included | Yes |
Warranty card | Yes |
Quick start guide | Yes |
Manual | Yes |
AC adapter included | Yes |
Packaging content |
---|
Power cord included | Yes |
Warranty card | Yes |
Quick start guide | Yes |
Manual | Yes |
AC adapter included | Yes |
Other features |
---|
On-board graphics adapter | Yes |
