Print quality |
---|
Vertical printing | Yes |
Maximum resolution | 300 x 300 DPI |
Printing |
---|
Vertical printing | Yes |
Print speed | 110 mm/sec |
Print speed | 92 lpm |
Maximum resolution | 300 x 300 DPI |
Print technology | Direct thermal |
Networking |
---|
Network ready | Yes |
Ports & interfaces |
---|
Standard interfaces | USB 2.0, Ethernet |
PC connected | Yes |
Memory |
---|
Internal memory | 2 MB |
Paper handling |
---|
Media thickness | 0.076 - 0.153/0.178 |
Maximum roll diameter | 101.6 |
Maximum label width | 4.02" (10.2 cm) |
Maximum label length | 118.1" (3 m) |
Performance |
---|
Number of label formats | 5 |
Number of styles | 7 |
Built-in barcodes | Codabar (NW-7),EAN13,EAN8,Maxicode,Postnet,QR Code,UPC-A,UPC-E |
Number of fonts | 5 |
Tape cutting | Automatic |
Design |
---|
Colour of product | Grey |
Weight & dimensions |
---|
Dimensions (WxDxH) | 6.81 x 9.02 x 6.22" (173 x 229 x 158 mm) |
Weight | 4.03 lbs (1.83 kg) |
Power |
---|
Power requirements | 220-240VAC, 50/60 Hz, 1.8A |
Technical details |
---|
Colour of product | Grey |
Number of label formats | 5 |
Label type | RD |
Number of styles | 7 |
Built-in barcodes | Codabar (NW-7),EAN13,EAN8,Maxicode,Postnet,QR Code,UPC-A,UPC-E |
Number of fonts | 5 |
Tape cutting | Automatic |
Maximum label width | 4.02" (10.2 cm) |
Maximum label length | 118.1" (3 m) |
Software |
---|
Bundled software | P-touch PT-Editor 5.0, Transfer Manager 2.1, Transfer Express, Library 2.1 |
System requirements |
---|
Mac compatibility | No |
Minimum RAM | 128 MB |
Minimum hard disk space | 70 MB |
Compatible operating systems | Windows XP/7, Windows Vista, Windows Server 2003/2008 |
Operational conditions |
---|
Operating temperature (T-T) | 10 - 35 °C |
Operating relative humidity (H-H) | 20 - 80% |
Packaging data |
---|
Package weight | 0.111 oz (3.15 g) |
Package dimensions (WxDxH) | 14.2 x 9.02 x 9.76" (360 x 229 x 248 mm) |
Packaging content |
---|
Bundled software | P-touch PT-Editor 5.0, Transfer Manager 2.1, Transfer Express, Library 2.1 |
Other features |
---|
Label type | RD |
Network ready | Yes |
Dimensions (WxDxH) | 6.81 x 9.02 x 6.22" (173 x 229 x 158 mm) |
