Asus H97M-E/CSM LGA1150/ Intel H97/ DDR3/ SATA3&USB3.0/ A&GbE/ MicroATX Motherboard

Specifications

• Mfr Part Number: H97M-E/CSM
• CPU: LGA1150
  • Supports the 5th/ New 4th/ 4th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • Supports Intel 22nm CPU
  • Supports Intel Turbo Boost Technology 2.0
• Chipset: Intel H97
• Memory: 4x DDR3-1600/1333 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0/2.0 x16 Slot, 3x PCI-Express 2.0 x1 Slots
• Storage:
  • SATA: 4x SATA3 Ports, Support RAID 0, 1, 5, 10
  • M.2: 1x M.2 Port (type 2260/ 2280), Support SATA & PCI-Express Mode

• Audio: Realtek ALC887 8-Channel High Definition Audio CODEC
• LAN: Realtek 8111GR Gigabit Ethernet Controller
• Ports: 6x USB 3.0/2.0 Ports (4 rear, 2 at mid-board), 8x USB 2.0/1.1 Ports (2 rear, 6 at mid-board), 1x PS/2 Keyboard Port, 1x PS/2 Mouse Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin EATX Power Connector, 1x 8pin ATX 12V Power Connector
• Form Factor: MicroATX, 9.6 x 7.8 inch / 24.4 x 19.8 cm
