ASRock Z170A-X1/3.1 LGA1151/ Intel Z170/ DDR4/ Quad CrossFireX/ SATA3&USB3.1/ A&GbE/ ATX Motherboard

Specifications

• Mfr Part Number: Z170A-X1/3.1
• CPU: LGA 1151
  • Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • 5 Power Phase Design
  • Supports Intel Turbo Boost 2.0 Technology
  • Supports Intel K-Series unlocked CPUs
  • Supports ASRock BCLK Full-range Overclocking
• Chipset: Intel Z170
• Memory: 4x DDR4-3466+(OC)/ 3200(OC)/ 2933(OC)/ 2800(OC)/ 2400(OC)/ 2133 DIMM Slots, Dual-Channel, Non-ECC, Unbuffered, Max capacity up to 64GB
• Slots: 2x PCI-Express 3.0 x16 Slots (one runs at x4), 3x PCI-Express 3.0 x1 Slots (Flexible PCIe)
• Multi-Graphics: Supports AMD Quad CrossFireX, CrossFireX
• SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10
• Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC, Supports Premium Blu-ray Audio
• LAN: Giga PHY Intel I219V Gigabit Ethernet Controller
• Ports: 2x USB 3.1 Ports (1 Type-A, 1 Type-C), 8x USB 3.0 Ports (2 rear, 6 via header), 4x USB 2.0 Ports (via header), 1x PS/2 Mouse Port, 1x PS/2 Keyboard Port, 1x DVI-D Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin 12V Power Connector
• Form Factor: ATX
