ASRock Rack E3C224D4HM LGA1150/ Intel C224/ DDR3/ SATA3&USB3.0/ V&2GbE/ Half Width Server Motherboard

Specifications

• Mfr Part Number: E3C224D4HM
• CPU: LGA1150
  • Supports Intel Xeon E3-1200 v3/v4 Series & 5th/ 4th Generation Core i3/Pentium/Celeron Processors
  • Supports Hyper-Threading Technology
• Chipset: Intel C224
• Memory: 4x 240pin DDR3-1600/1333 DIMM Slots, Dual Channel, ECC, Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot
• SATA: 4x SATA3 Ports, Support RAID 0, 1, 5, 10 and Intel Rapid Storage
• Video: Aspeed AST2300 Graphics w/ 16MB DDR3 VRAM Video Memory
• LAN: 2x Intel i210 Gigabit Ethernet Controllers, 1x Realtek RTL8211E for Dedicated Management LAN
• Ports: 3x USB 3.0 Ports (1 rear, 2 via header), 3x USB 2.0 Ports (2 via header, 1 Type A), 1x VGA Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin ATX Power Connector
• Form Factor: Half Width, 13.00 x 5.96 inch / 33.0 x 15.1 cm
