ASRock H97M-ITX/AC LGA1150/ Intel H97/ DDR3/ SATA3&USB3.0/ WiFi/ A&GbE/ Mini-ITX Motherboard

Specifications

• Mfr Part Number: H97M-ITX/AC
• CPU: LGA1150
  • Supports 5th/ New 4th/ 4th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • 4 Power Phase design
  • Supports Intel Turbo Boost 2.0 Technology
• Chipset: Intel H97
• Memory: 2x DDR3-1600/ 1333/ 1066 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 16GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x Mini-PCI Express Slot (Vertical Half, for WiFi + BT Module)
• SATA: 5x SATA3 Ports, Support RAID 0, 1, 5, 10
• Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC; Supports Premium Blu-ray Audio
• LAN: Qualcomm Atheros AR8171 PCI-Express x1 Gigabit Ethernet Controller; IEEE 802.11a/b/g/n/ac Wireless LAN (2.4/5GHz); Bluetooth 4.0 / 3.0 + High speed class II
• Ports: 6x USB 3.0 Ports (4 rear, 2 via header), 4x USB 2.0 Ports (2 rear, 2 via header), 1x PS/2 Keyboard/Mouse Combo Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x Optical SPDIF Out, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 4pin 12V Power Connector
• Form Factor: Mini-ITX
