ASRock FM2A58M-HD+ Socket FM2+/ AMD A58 FCH/ DDR3/ A&GbE/ MicroATX Motherboard

Specifications

• Mfr Part Number: FM2A58M-HD+
• CPU: Socket FM2+
  • Supports Socket FM2+ 95W / FM2 100W Processors
• Chipset: AMD A58 FCH (Bolton-D2)
• Memory: 2x DDR3-1866/ 1600/ 1333/ 1066 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 1x PCI-Express 3.0 x16 Slot, 1x PCI-Express 2.0 x1 Slot, 1x PCI Slot
• SATA: 6x SATA2 Ports, Support RAID 0, 1, 10
• Audio: Realtek ALC662 5.1-Channel High Definition Audio CODEC
• Video: Integrated AMD Radeon R7/R5 Series Graphics in A-Series APU w/ 2GB Max Shared Memory
• LAN: Realtek RTL8111FR PCI-Express x1 Gigabit Ethernet Controller
• Ports: 10x USB 2.0 Ports (6 rear, 4 via headers), 1x PS/2 Keyboard Port, 1x PS/2 Mouse Port, 1x VGA Port, 1x DVI-D Port, 1x HDMI Port, 1x RJ45 LAN Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 4pin 12V Power Connector
• Form Factor: MicroATX, 9.2 x 7.2 inch / 23.4 x 18.3 cm
