APC Smart-UPS SC620 4-Outlet 620VA 390W UPS System

SpecificationsMfr Part Number: SC620Output:Output Power Capacity: 390 Watts / 620 VAMax Configurable Power: 390 Watts / 620 VANominal Output Voltage: 120 VOutput Voltage Distortion: Less than 5% at full loadOutput Frequency (sync to mains): 47~53Hz for 50Hz nominal, 57~63Hz for 60Hz nominalCrest Factor: Upto 5:1Waveform Type: Stepped approximation to a sinewaveOutput Connections: 4x NEMA 5-15RInput:Nominal Input Voltage: 120 VInput Frequency: 50/60Hz ± 3Hz (auto sensing)Input Connections: NEMA 5-15PCord Length: 6 feet / 1.83 metersInput voltage range for main operations: 82~144 VInput voltage adjustable range for mains operation: 75~154 VBatteries & Runtime:Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte - leakproofTypical recharge time: 5 hoursReplacement battery cartridge: RBC4RBC Quantity: 1Typical Backup Time(at Half Load): 15.7 minutes (195 Watts)Typical Backup Time(at Full Load): 5.5 minutes (390 Watts)Communications & Management:Interface Port: DB-9 RS-232Control panel: LED status display with On Line - On Battery - Replace Battery and Overload indicatorsAudible Alarm: Alarm when on battery - distinctive low battery alarm - overload continuous tone alarmEmergency Power Off (EPO): OptionalSurge Protection and Filtering:Surge energy rating: 412 JoulesFiltering: Full time multi-pole noise filtering - 0.3% IEEE surge let-through - zero clamping response time - meets UL 1449Dataline protection: RJ-45 Modem/ Fax/ DSL/ 10-100 Base-T protectionAudible noise at 1 meter from surface of unit: 45 dBAOnline Thermal Dissipation: 70.00 BTU/hrRegulatory Approvals: CSA, FCC Part 15 Class A, UL 1778Color: GreyDimensions (WxDxH): 4.7 x 14.5 x 6.6 inch / 119 x 368 x 168 mmWeight: 27 lbs / 12.27 kg
