ASRock Rack EP2C612D8-2T8R Dual LGA2011-v3/ Intel C612/ DDR4/ SATA3&SAS3&USB3.0/ V&2GbE/ ATX Server Motherboard

Specifications

• Mfr Part Number: EP2C612D8-2T8R
• CPU: Dual LGA2011-v3
  • Support Intel Xeon E5-2600/ 4600 & v3 Series Processors
• Chipset: Intel C612
• Memory: 8x DDR4-2133/ 1866/ 1600 DIMM Slots, Quad Channel
• Slots: 2x PCI-Express 3.0 x16 Slots, 1x PCI-Express 3.0 x8 Slot
• SATA: 10x SATA3 Ports
• SAS: LSI3008 Support 8x SAS3 12Gbps by 2x Mini SAS HD Connectors
• Video: Aspeed AST2400 Graphics w/ 16MB DDR3 Video Memory
• LAN: 2x Intel X540 10-Gigabit Ethernet Controllers; 1x Realtek RTL8211E for Dedicated Management GLAN
• Ports: 4x USB 3.0 Ports (2 rear, 2 via header), 4x USB 2.0 Ports (2 rear, 2 via header), 1x VGA Port, 1x Serial Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
• Power Connector: 1x 24pin ATX Power Connector, 2x 8pin ATX Power Connectors
• Form Factor: ATX, 12.0 x 10.0 inch / 30.5 x 25.4 cm
